RF3355C
Pb
•
•
•
•
Ideal Front-End Filter for Wireless Receivers
Low-Loss, Coupled-Resonator Quartz Design
Simple External Impedance Matching
Complies with Directive 2002/95/EC (RoHS)
The RF3355C is a low-loss, compact, and economical surface-acoustic-wave (SAW) filter designed to pro-
vide front-end selectivity in 390 MHz receivers. Receiver designs using this filter include superhet with
10.7 MHz or 500 kHz IF, direct conversion and superregen. Typical applications of these receivers are wire-
less remote-control and security devices.
This coupled-resonator filter (CRF) uses selective null placement to provide suppression, typically greater
than 40 dB, of the LO and image spurious responses of superhet receivers with 10.7 MHz IF. RFM’s ad-
vanced SAW design and fabrication technology is utilized to achieve high performance and very low loss with
simple external impedance matching.
390.0 MHz
SAW Filter
SM5050-8 Case
5x5
Electrical Characteristics
Characteristic
Center Frequency at 25°C
Tolerance from 390.0 MHz
Minimum Insertion Loss 389.82 -390.22 MHz
Passband (relative to IL
min
)
Passband (relative to IL
min
)
Attenuation: (relative to IL
min
)
0 - 345 MHz
345 - 370 MHz
370 - 388.94 MHz
391.5 - 410 MHz
410 - 475 MHz
475 - 1000 MHz
Impedance at F
C
; Input Z
IN
=R
IN
//C
IN
Output Z
OUT
=R
OUT
//C
OUT
Turnover To
Frequency Aging
Absolute Value During the First Year
Reel Size 7 Inch
Reel Size 13 Inch
Lid Symbolization (in addition to Lot and/or Date Codes)
Standard Reel Quantity
1
1
3, 4
3, 4
1
389.77 -390.2
389.71 -390.26
BW
3
Absolute Frequency
Sym
f
C
∆f
C
IL
min
Notes
1, 2
1, 2
1
1
1
500
45
40
15
8
35
45
2.0
1.5
2.0
1100
50
45
25
13
45
55
344Ω // 4.9pF
344Ω // 4.9pF
25
≤10
ppm/yr Typical
736 // YWWS
500 Pieces/Reel
3000 Pieces/Reel
°C
dB
Minimum
Typical
390.0
±100
4.0
3.0
6.0
Maximum
Units
MHz
kHz
dB
dB
kHz
