ZWD100PAF-0524/J datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> ZWD100PAF-0524/J

ZWD100PAF-0524/J: DescriptionAC-DC Power Factor Correction Module,; CategoryPower/power management The power supply circuit; File Size680KB，4 Pages; ManufacturerTDK-LAMBDA

Download Datasheet Parametric Compare View All

ZWD100PAF-0524/J Overview

AC-DC Power Factor Correction Module,

ZWD100PAF-0524/J Parametric

Parameter Name	Attribute value
Maker	TDK-LAMBDA
Reach Compliance Code	compliant
Analog Integrated Circuits - Other Types	AC-DC POWER FACTOR CORRECTION MODULE

Preview

Download Datasheet

View All

• Universal Input (85 - 265VAC)

• Power Factor Corrected

• 200% Peak Power capability on 24V output

• 2 Year Warranty

• Individual output adjustment

Key Market Segments & Applications

ZWD-PAF Series

100W to 440W

Dual Output Power Supplies

ZWD-PAF Features and Benefits

Features

• Input Transient Protected

• Power Factor Corrected

• 200% Peak Power Capability

Factory Automation

Printer and Motor Drives

Kiosks

Benefits

• Withstands Harsh Environments

• Supports Global Use

• Can Drive High current Start Up Devices or pulse loads

Specifications

MODEL

ITEMS

Input Voltage

Input Current

Inrush Current

(1)(2)

Power Factor

Leakage Current

Temperature Coefficient

Overcurrent Protection

Overvoltage Protection

Hold Up Time (Typ)

Efficiency

Remote On/Off

Line Regulation

Load Regulation

Ripple & Noise

Operating Temperature

Storage Temperature

Humidity (non condensing)

Cooling

Withstand Voltage

Isolation Resistance

Vibration (non operating)

Shock

Safety Agency Approvals

Conducted & Radiated EMI

Immunity

Weight (Typ)

Size (WxHxD)

Warranty

yrs

ZWD100PAF-0524

ZWD150PAF-0524

ZWD225PAF-0524

(1)

(3)

(4)

(1)

(2)

85-265VAC (47-63Hz), 120-370VDC

1.3 / 0.65

1.9 / 0.97

2.81 / 1.43

15 / 30

0.99 at 100VAC, 0.95 at 200VAC, Meets EN61000-3-2

0.75mA max

<0.02%/°C

5V output: >105%, 24V output: >205%

120- 145%

5V output: 40ms, 24V output: 20ms

79 / 81

80 / 82

81 / 83

On 24V output only, remove jumper to shutdown

5V output: 20mV, 24V output: 96mV

5V output: 40mV, 24V output: 150mV

5V output: 120mV, 24V output: 150mV

(Open frame or L bracket) -10°C to +70°C, derate linearly to 0% load from 50°C to 70°C

(With /A cover option) -10°C to +60°C, derate linearly to 0% load from 40°C to 60°C

-30 to +85°C

Operating: 20 - 90%RH, Non-operating: 10 - 95% RH

Convection cooled

I/P to Gnd 2kVAC (20mA), I/P to O/P 3kVAC (20mA), O/P to Gnd 500VAC (100mA) for 1 min.

>100M at 25°C & 70%RH, Output to Ground 500VDC

10 - 55Hz (1 minute sweep), 19.6m/s

constant X, Y, Z 1 hour

< 196.1 m/s

EN60950-1, UL/CSA60950-1, EN50178, CE Mark

EN55022-B, FCC Class B, VCCI-B

EN61000-4-2, -3, -4, -5, -6, -8, -11

460 (780 with cover)

530 (885 with cover)

670 (1065 with cover)

222 x 75 x 35

222 x 85 x 40

222 x 95 x 45

2 Years

Notes:

See installation manual for full specification.

(1) 100/200VAC (2) 25°C ambient (cold start) (3) Avoid prolonged operation in overload (4) OVP on 24V output will shutdown 24V output only
