ZY6V2GP THRU ZY200GP
Glass Passivated Zener Diode
FEATURES
5.8V-188V
2W
•
Glass passivated junction
•
The plastic material carries
U/L recognition 94 V-0
•
Terminals: Axial Leads
•
Polarity: Color band denotes cathode
Mechanical Data
.Min. distance from body to soldering point, 4 mm.
Max. solder temperature, 350 °C.
Max. soldering time, 3.5 sec.
Do not bend lead at a point closer than
2 mm. to the body.
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Maximum Ratings, according to IEC publication No. 134
P
tot
P
ZSM
T
j
T
stg
Power dissipation at Tamb = 25 ºC
Non repetitive peak zener dissipation
(t = 10 ms)
Operating temperature range
Storage temperature range
2W
60 W
– 65 to + 175 °C
– 65 to + 175 °C
Electrical Characteristics at Tamb = 25 °C
R
thj-a
Max. thermal resistance at:
10 mm. lead length
60 °C/W
E-mail: sales@taychipst.com
1 of 2
Web Site: www.taychipst.com
ZY6V2GP THRU ZY200GP
Glass Passivated Zener Diode
5.8V-188V
2W
Type
Zener (1)
Voltage
Range
V
Z
at I
ZT
Maximum
Zener
Impedance
Z
ZT
at
I
ZT
Test
Current
I
ZT
Temp
coef. of
Zener
Volt.
Min Reverse
Voltage
at I
R
= 1
µ
A
V
R
Max
Regulator
Current at 45 ºC
I
ZM
(mA)
245
220
200
180
165
145
135
120
110
98
90
80
72
66
60
53
48
44
40
37
33
30
27
25
21
20
18
16
15
13
12
11
10
9
8.5
8.0
7.5
(V)
ZY6V2GP
ZY6V8GP
ZY7V5GP
ZY8V2GP
ZY9V1GP
ZY10GP
ZY11GP
ZY12GP
ZY13GP
ZY15GP
ZY16GP
ZY18GP
ZY20GP
ZY22GP
ZY24GP
ZY27GP
ZY30GP
ZY33GP
ZY36GP
ZY39GP
ZY43GP
ZY47GP
ZY51GP
ZY56GP
ZY62GP
ZY68GP
ZY75GP
ZY82GP
ZY91GP
ZY100GP
ZY110GP
ZY120GP
ZY130GP
ZY150GP
ZY160GP
ZY180GP
ZY200GP
(1) Tested with pulses.
Pulse test: tp
≤
50 ms;
δ
< 2%
(Ω)
2
2
2
2
4
4
7
7
10
10
15
15
15
15
15
15
15
15
40
40
45
45
60
60
80
80
100
100
200
200
250
250
300
300
350
350
350
(mA)
100
100
100
100
50
50
50
50
50
50
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
10
5
5
5
5
5
5
5
5
5
(% / ºC)
+0.025
+0.035
+0.035
+0.055
+0.055
+0.070
+0.075
+0.075
+0.075
+0.075
+0.085
+0.085
+0.085
+0.085
+0.085
+0.085
+0.085
+0.085
+0.085
+0.085
+0.095
+0.095
+0.095
+0.095
+0.105
+0.105
+0.105
+0.105
+0.110
+0.110
+0.110
+0.110
+0.110
+0.110
+0.110
+0.110
+0.110
(V)
1.5
2
2
3.5
6.9
7.5
8.3
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.5
22.8
25
27.4
29.6
32.7
35.7
38.8
42.5
47.1
51.7
57
62.4
69.2
76
83.5
91.2
98.2
114
122
137
152
5.8-6.6
6.4-7.2
7.0-7.9
7.7-8.7
8.5-9.6
9.4-10.6
10.4-11.6
11.4-12.7
12.4-14.1
13.8-15.8
15.3-17.1
16.8-19.1
18.8-21.2
20.8-23.3
22.8-25.6
25.1-28.9
28-32
31-35
34-38
37-41
40-46
44-50
48-54
52-60
58-66
64-72
70-79
77-88
85-96
94-106
104-116
114-127
124-141
138-156
153-171
168-191
188-212
