1.38
REF
3X FEMALE CONTACTS
0.055 X 0.187 REF
COVER
1.270±0.004
R0.160
C
L
PART NUMBER
EAC405030
EAC405040
EAC405050
EAC405060
0.975±0.004
PANEL ID
NUMBER
030
040
050
060
PANEL
THICKNESS
0.026-0.040
0.036-0.050
0.046-0.060
0.056-0.070
A
C
L
C
L
1.08
REF
0.74
REF
RECOMMENDED
FRONT MOUNTING CUT-OUT
A
SECTION A-A
1.26
REF
C
L
PANEL ID NUMBER
SEE TABLE
3X SLOT
0.090 x 0.120
HOUSING
0.96
REF
C
L
0.16
0.238
REF
0.79
REF
1.050
REF
PANEL THICKNESS
1.290
NOTES:
C
L
1. MEETS IEC 60320 SPECIFICATION
0.276
2. AGENCY APPROVAL & RATING:
VDE:10A, 250V AC.
UL & CSA:15A, 250V AC.
3. MATERIALS:
HOUSING, BLACK POLYESTER
COVER, BLACK POLYESTER
CONTACTS, TIN PLATED COPPER ALLOY
0.276
0.079
CUSTOMER DRAWING
THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED
BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.
C
L
0.613
REF
UNLESS OTHERWISE SPECIFIED
1. ALL DIMENSIONS IN INCHES
- TWO PLACE DECIMALS
0.02
0.005
SIZE
FINISH
WIDTH
MULT
LBS/M
MATERIAL
SPEC No.
TEMPER
0.079
G
F
26912
25129
ECO NUMBER
- THREE PLACE DECIMALS
02/16/12
03/27/02
DATE
SPEC No.
FIRST USED ON
DATE DRAWN
BY
CHKD
SCALE
2:1
BL
BL
BY
TJK
TJK
APVD
11/03/86
LH
AM
11/17/86
RP
05/06/87
PART No.
APVD
SHEET
1
OF
1
REV
0.895
REF
REV
REVISIONS
DO NOT SCALE DRAWING
NAME
SNAP-IN FEMALE
RECEPTACLE
EAC405 SERIES
G
SolidWorks CAD File
B
