YAGeo CorPorATIoN
INDUCTORS / BEADS
SLM Series
APPLICATIONS
Televisions, VCrs and PC
DC-DC converters and other electronic equipments
DIP Power Inductors
FEATURES
Halogen Free Products
Unshield Construction
DIP Drum Inductor
PRODUCT IDENTIFICATION
SLM
☐☐☐☐
-
☐☐☐☐
-
☐
-
☐☐
Internal No.
Vertical / Horizontal
Tolerance
Inductance
Dimensions
Product Symbol
■
Tolerance: J = ±5%, K = ±10%, L = ±15%, M = ±20%,
■
Internal No.: HF = Halogen Free
P = ±25%, N = ±30%, Y = min
SHAPES AND DIMENSIONS
A
Unit: mm
XXX
B
C
E
TYPE
SLM0709
SLM0808
SLM1112
A
7.7
8.5 ± 0.3
11.2 ± 0.3
B
9.5
8.3 ± 0.5
12.2 ± 0.3
C
5.0 ± 1.0
5.0 ± 1.0
5.0 ± 1.0
D
3.5
5 +0.8/-0.5
5 +1.0/-0.5
E
ø 0.60 ± 0.05
ø 0.60 ± 0.05
ø 0.65 ± 0.05
D
Land Pattern
b
a
176
ELECTRICAL CHARACTERISTICS
SLM0709
PART NO.
INDUCTANCE
(µH)
1.00
1.50
2.20
3.30
4.70
6.80
10.0
15.0
22.0
33.0
47.0
68.0
100
150
220
330
470
680
1,000
1,500
TOLERANCE
(±%)
20.0
20.0
20.0
20.0
20.0
20.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
DC RESISTANCE
(
Ω
) Max.
0.006
0.008
0.011
0.018
0.022
0.028
0.043
0.056
0.086
0.140
0.170
0.280
0.330
0.560
0.720
1.100
1.700
2.300
4.300
5.000
NOMINAL CURRENT
(A) Max.
6.60
5.40
4.00
3.60
3.10
2.50
2.10
1.70
1.40
1.10
0.96
0.79
0.66
0.53
0.44
0.36
0.30
0.25
0.20
0.17
SLM0709-1r0M-□-HF
SLM0709-1r5M-□-HF
SLM0709-2r2M-□-HF
SLM0709-3r3M-□-HF
SLM0709-4r7M-□-HF
SLM0709-6r8M-□-HF
SLM0709-100K-□-HF
SLM0709-150K-□-HF
SLM0709-220K-□-HF
SLM0709-330K-□-HF
SLM0709-470K-□-HF
SLM0709-680K-□-HF
SLM0709-101K-□-HF
SLM0709-151K-□-HF
SLM0709-221K-□-HF
SLM0709-331K-□-HF
SLM0709-471K-□-HF
SLM0709-681K-□-HF
SLM0709-102K-□-HF
SLM0709-152K-□-HF
Note:
Inductance test frequency at 1 KHz
Isat: DC current at which the inductance drops 10% from its value without current
Irms: The actual current when temperature of coil becomes
ΔT
= 25 °C
177
ELECTRICAL CHARACTERISTICS
SLM0808
PART NO.
INDUCTANCE TOLERANCE
(µH)
(±%)
3.30
4.70
6.80
10.0
15.0
22.0
33.0
47.0
68.0
100
150
220
330
470
680
1,000
1,500
20.0
20.0
20.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
Q
Min.
10
10
10
20
20
20
20
20
20
20
20
15
15
15
15
30
30
TEST FREQUENCY
L/Q (MHz) Min.
1K / 7.96M
1K / 7.96M
1K / 7.96M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 796K
1K / 796K
1K / 796K
1K / 796K
1K / 796K
1K / 796K
1K / 252K
1K / 252K
DC RESISTANCE
(
Ω
) Max.
0.017
0.021
0.025
0.031
0.042
0.070
0.092
0.130
0.160
0.250
0.400
0.530
0.780
1.000
1.500
2.200
3.500
Isat
(A) Max.
4.50
3.80
3.20
2.60
2.10
1.70
1.40
1.20
1.00
0.80
0.67
0.54
0.45
0.38
0.32
0.26
0.21
Irms
(A) Max.
3.80
3.50
3.10
2.70
2.40
1.90
1.50
1.30
1.10
0.94
0.73
0.64
0.52
0.46
0.37
0.30
0.25
SLM0808-3r3M-□-HF
SLM0808-4r7M-□-HF
SLM0808-6r8M-□-HF
SLM0808-100K-□-HF
SLM0808-150K-□-HF
SLM0808-220K-□-HF
SLM0808-330K-□-HF
SLM0808-470K-□-HF
SLM0808-680K-□-HF
SLM0808-101K-□-HF
SLM0808-151K-□-HF
SLM0808-221K-□-HF
SLM0808-331K-□-HF
SLM0808-471K-□-HF
SLM0808-681K-□-HF
SLM0808-102K-□-HF
SLM0808-152K-□-HF
Note:
Inductance test frequency at 1 KHz
Isat: DC current at which the inductance drops 10% from its value without current
Irms: The actual current when temperature of coil becomes
ΔT
= 25 °C
178
ELECTRICAL CHARACTERISTICS
SLM1112
PART NO.
INDUCTANCE TOLERANCE
(µH)
(±%)
1.00
2.20
3.30
4.70
6.80
10.0
15.0
22.0
33.0
47.0
68.0
100
150
220
330
470
680
1,000
1,500
2,200
3,300
4,700
6,800
10,000
15,000
20.0
20.0
20.0
20.0
20.0
20.0
20.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Q
Min.
15
15
10
10
10
20
20
20
30
30
20
20
20
20
20
10
10
20
30
20
30
30
30
30
50
TEST FREQUENCY
L/Q (MHz) Min.
1K / 7.96M
1K / 7.96M
1K / 7.96M
1K / 7.96M
1K / 7.96M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 2.52M
1K / 796K
1K / 796K
1K / 796K
1K / 796K
1K / 796K
1K / 796K
1K / 796K
1K / 252K
1K / 252K
1K / 252K
1K / 252K
1K / 252K
1K / 79.6K
1K / 79.6K
DC RESISTANCE
(
Ω
) Max.
0.058
0.073
0.010
0.015
0.016
0.025
0.029
0.040
0.062
0.075
0.130
0.160
0.260
0.330
0.520
0.660
1.100
1.400
2.400
3.200
4.900
7.600
0.450
0.380
0.290
Isat
(A) Max.
14.0
10.0
8.80
7.20
6.10
5.00
4.20
3.40
2.80
2.30
1.90
1.60
1.30
1.10
0.88
0.75
0.61
0.51
0.43
0.35
0.28
0.24
9.8
18
24
Irms
(A) Max.
7.70
6.70
5.90
4.80
4.60
3.70
3.40
2.90
2.30
2.10
1.60
1.40
1.10
1.00
0.82
0.72
0.56
0.50
0.38
0.33
0.26
0.21
0.20
0.17
0.13
SLM1112-1r0M-□-HF
SLM1112-2r2M-□-HF
SLM1112-3r3M-□-HF
SLM1112-4r7M-□-HF
SLM1112-6r8M-□-HF
SLM1112-100M-□-HF
SLM1112-150M-□-HF
SLM1112-220K-□-HF
SLM1112-330K-□-HF
SLM1112-470K-□-HF
SLM1112-680K-□-HF
SLM1112-101K-□-HF
SLM1112-151K-□-HF
SLM1112-221K-□-HF
SLM1112-331K-□-HF
SLM1112-471K-□-HF
SLM1112-681K-□-HF
SLM1112-102J-□-HF
SLM1112-152J-□-HF
SLM1112-222J-□-HF
SLM1112-332J-□-HF
SLM1112-472J-□-HF
SLM1112-682J-□-HF
SLM1112-103J-□-HF
SLM1112-153J-□-HF
Note:
Inductance test frequency at 1 KHz
Isat: DC current at which the inductance drops 10% from its value without current
Irms: The actual current when temperature of coil becomes
ΔT
= 25 °C
