SC30R22KB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> SC30R22KB

SC30R22KB: Description1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, AXIAL LEADED, ROHS COMPLIANT; CategoryPassive components inductor; File Size97KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

SC30R22KB Overview

1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, AXIAL LEADED, ROHS COMPLIANT

SC30R22KB Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1646066960
Reach Compliance Code	unknown
ECCN code	EAR99
DC Resistance	0.14 Ω
Nominal inductance(L)	0.22 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	SC30
Number of functions	1
Number of terminals	2
Minimum quality factor (at nominal inductance)	33
Maximum rated current	1.12 A
Shape/Size Description	TUBULAR PACKAGE
shield	NO
surface mount	NO
Terminal location	AXIAL
Terminal shape	WIRE
Tolerance	10%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Passive C omponents

Product Feature Selector

> Product Details

SC30R22KB Product Details

Live Product Chat

Inductors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

SC30R22KB

(1624048-1)

T E I nternal N umber: 1 6 2 4 0 4 8 - 1

Product Highlights:

Inductor

Inductor Type = Radio Frequency

Lead Type = Axial Leaded

Wirewound

Inductance = .22 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Axial Leaded Power Inductors - Type SC 10, SC 15, SC 30...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Inductor

Inductor Type = Radio Frequency

Element

= Wirewound

Shielded

= No

Electrical Characteristics:

Inductance (?H)

= 0.22

DC Resistance (?)

= 0.14

C urrent, Maximum (mA)

= 1120

Quality Factor

= 33

Package Type

= Ammo Packed

Tolerance (%) = 10

Body Related Features:

Lead Type

= Axial Leaded

Series

= SC 30

Package, C omponent Size

= 7.0 x 2.7

Mount Style

= Through-Hole

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Operation/Application:

Application

= Radio Frequency

Other:

Brand = Sigma Inductors

Additional Information:

Product Line Information

SC30R22KB Related Products

	SC30R22KB	1624048-1
Description	1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, AXIAL LEADED, ROHS COMPLIANT	1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, AXIAL LEADED, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
Objectid	1646066960	1646063308
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
DC Resistance	0.14 Ω	0.14 Ω
Nominal inductance(L)	0.22 µH	0.22 µH
Inductor Applications	POWER INDUCTOR	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	SC30	SC30
Number of functions	1	1
Number of terminals	2	2
Minimum quality factor (at nominal inductance)	33	33
Maximum rated current	1.12 A	1.12 A
Shape/Size Description	TUBULAR PACKAGE	TUBULAR PACKAGE
shield	NO	NO
surface mount	NO	NO
Terminal location	AXIAL	AXIAL
Terminal shape	WIRE	WIRE
Tolerance	10%	10%
