TTA1586FU
TOSHIBA Transistor
Silicon PNP Epitaxial Type (PCT process)
TTA1586FU
Audio Frequency General Purpose Amplifier Applications
•
•
•
•
•
•
High voltage and high current: V
CEO
=
−50
V, I
C
=
−150
mA (max)
Excellent hFE linearity:
hFE (IC =
−0.1
mA)/ hFE (IC =
−2
mA)
= 0.95 (typ.)
Unit: mm
High hFE: hFE = 120 to 400
Low noise: NF = 1dB (typ.), 10dB (max)
Complementary to 2SC4116
Small package
Absolute Maximum Ratings (Ta
=
25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
−50
−50
−5
−150
−30
100
150
−55
to 150
Unit
V
V
V
mA
mA
mW
°C
°C
JEDEC
JEITA
―
SC-70
Note: Using continuously under heavy loads (e.g. the application of high
TOSHIBA
2-2E1A
temperature/current/voltage and the significant change in
Weight: 6 mg (typ.)
temperature, etc.) may cause this product to decrease in the
reliability significantly even if the operating conditions (i.e.
operating temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Electrical Characteristics (Ta
=
25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-emitter saturation voltage
Transition frequency
Collector output capacitance
Noise figure
Symbol
I
CBO
I
EBO
h
FE
V
CE (sat)
f
T
C
ob
NF
Test Condition
V
CB
= −50
V, I
E
=
0
V
EB
= −5
V, I
C
=
0
V
CE
= −6
V, I
C
= −2
mA
I
C
= −100
mA, I
B
= −10
mA
V
CE
= −10
V, I
C
= −1
mA
V
CB
= −10
V, I
E
=
0, f
=
1 MHz
V
CE
= −6
V, I
C
= −0.1
mA, f
=
1 kHz,
Rg
=
10 kΩ
Min
⎯
⎯
120
⎯
80
⎯
⎯
Typ.
⎯
⎯
⎯
−0.1
⎯
4
1.0
Max
−0.1
−0.1
400
−0.3
⎯
7
10
V
MHz
pF
dB
Unit
μA
μA
Marking
Type Name
BP2
1
2010-06-25
TTA1586FU
