HSMA3100

Description
Schottky Barrier Rectifiers (Reverse Voltage 20 to 100V, Forward Current 3A)
CategoryDiscrete semiconductor    diode
File Size79KB,3 Pages
ManufacturerHSMC
Websitehttp://www.hsmc.com.tw/
Download Datasheet Parametric Compare View All

HSMA3100 Overview

Schottky Barrier Rectifiers (Reverse Voltage 20 to 100V, Forward Current 3A)

HSMA3100 Parametric

Parameter NameAttribute value
MakerHSMC
package instructionSMA, 2 PIN
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresHIGH RELIABILITY
applicationGENERAL PURPOSE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.8 V
JEDEC-95 codeDO-214AC
JESD-30 codeR-PDSO-C2
Maximum non-repetitive peak forward current80 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-65 °C
Maximum output current3 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
GuidelineIEC-61000-4-2
Maximum repetitive peak reverse voltage100 V
Maximum reverse current100 µA
surface mountYES
technologySCHOTTKY
Terminal formC BEND
Terminal locationDUAL
HI-SINCERITY
MICROELECTRONICS CORP.
Spec. No. : HSMA200703
Issued Date : 2007.11.01
Revised Date : 2009.12.17
Page No. : 1/3
HSMA320
thru
HSMA3100
Schottky Barrier Rectifiers
(Reverse Voltage 20 to 100V, Forward Current 3A)
Features
Low Forward Voltage Drop
High Current Capability
High Reliability
High Surge Current Capabilit
Electrostatic discharge(ESD) test under IEC6100-4-2 standard>15kV(Air) & 8kV(Contact)
DO-214AC(SMA)
Mechanical Data
Case: JEDEC DO-214AC(SMA) molded plastic
Polarity: Indicated by cathode band
Weight: 0.002 ounce, 0.064 gram
Maximum Ratings & Electrical Characteristics
Ratings at 25°C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load. For capacitive load. Derate current by 20%.
Ratings
Repetitive Peak Reverse Voltage
Surge Peak Reverse Voltage
DC Blocking Voltage
Average Forward Rectified Current (T
A
=75 C)
Peak Forward Surge Current, 50Hz Half
o
Sine-wave (T
A
=25 C)
Repetitive Peak Forward C (f>15Hz)
Instantaneous Forward Voltage
Leakage Current (T
J
=25 C, V
R
=V
RRM
)
Leakage Current (T
J
=100 C, V
R
=V
RRM
)
Typical Junction Capacitance
Rating for Fusing, t<10ms (T
A
=25 C)
Thermal Resistance Junction to Ambient Air
Thermal Resistance Junction to Lead
Operating Junction Temperature Range
Storage Temperature Range
ESD Protection Voltage
o
o
o
o
Symbol
V
RRM
V
RSM
V
DC
I
FAV
I
FSM
I
FRM
V
F
I
R
C
J
it
R
θ
JA
R
θ
JL
T
J
T
STG
V
ESD
2
HSMA HSMA HSMA HSMA HSMA HSMA HSMA HSMA
320
330
340
345
350
360
380
3100
20
14
20
30
21
30
40
28
40
45
31.5
45
3
80
12
0.48
0.52
0.1
20
170
12.5
50
15
-65 to +125
-65 to +150
>8
0.7
0.8
50
35
50
60
42
60
80
57
80
100
71
100
Unit
V
V
V
A
A
A
V
mA
mA
pF
As
°C/W
°C/W
°C
°C
KV
2
HSMA320 thru HSMA3100
HSMC Product Specification
