DMC56402
Silicon NPN epitaxial planar type
For digital circuits
DMC26402 in SMini6 type package
Features
Low collector-emitter saturation voltage V
CE(sat)
Contributes to miniaturization of sets, reduction of component count.
Eco-friendly Halogen-free package
Package
Code
SMini6-F3-B
Package dimension clicks here.→
Click!
Basic Part Number
Dual DRC2124E (Individual)
Packaging
DMC564020R Embossed type (Thermo-compression sealing): 3000 pcs / reel (standard)
Name
Pin
1: Emitter (Tr1)
2: Base (Tr1)
3: Collector (Tr2)
4: Emitter (Tr2)
5: Base (Tr2)
6: Collector (Tr1)
Marking Symbol: F8
Internal Connection
(C1)
6
Tr1
Absolute Maximum Ratings
T
a
= 25°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Collector current
Total power dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
I
C
P
T
T
j
T
stg
Rating
50
50
100
150
150
–55 to +150
Unit
V
V
mA
mW
°C
°C
(B2)
5
R
1
R
2
R
2
(E2)
4
R
1
Tr2
1
(E1)
2
(B1)
3
(C2)
Resistance value
R
1
R
2
22
22
kΩ
kΩ
Electrical Characteristics
T
a
= 25°C±3°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Collector-base cutoff current (Emitter open)
Collector-emitter cutoff current (Base open)
Emitter-base cutoff current (Collector open)
Forward current transfer ratio
Collector-emitter saturation voltage
Input voltage (ON)
Input voltage (OFF)
Input resistance
Resistance ratio
Symbol
V
CBO
V
CEO
I
CBO
I
CEO
I
EBO
h
FE
V
CE(sat)
V
I(on)
V
I(off)
R
1
R
1
/ R
2
Conditions
I
C
= 10 µA, I
E
= 0
I
C
= 2 mA, I
B
= 0
V
CB
= 50 V, I
E
= 0
V
CE
= 50 V, I
B
= 0
V
EB
= 6 V, I
C
= 0
V
CE
= 10 V, I
C
= 5 mA
I
C
= 10 mA, I
B
= 0.5 mA
V
CE
= 0.2 V, I
C
= 5 mA
V
CE
= 5 V, I
C
= 100 µA
–30%
0.8
22
1.0
2.6
0.8
+30%
1.2
60
0.25
Min
50
50
0.1
0.5
0.2
Typ
Max
Unit
V
V
µA
µA
mA
V
V
V
kΩ
Note) Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
Publication date: February 2012
Ver. BED
1
This product complies with the RoHS Directive (EU 2002/95/EC).
DMC56402
DMC56402_PT-Ta
DMC56402_IC-VCE
DMC56402_hFE-IC
P
T
T
a
250
120
T
a
=
25°C
I
C
V
CE
I
B
=
350
µA
300
µA
250
µA
200
µA
60
150
µA
40
20
50
µA
0
100
µA
400
h
FE
I
C
V
CE
=
10 V
T
a
=
85°C
300
Total power dissipation P
T
(mW)
Collector current I
C
(mA)
200
80
Forward current transfer ratio h
FE
100
150
25°C
−30°C
100
200
50
100
0
0
40
80
120
160
200
0
2
4
6
8
10
12
0
0.1
1
10
100
Ambient temperature T
a
(
°C
)
DMC56402_VCEsat-IC
Collector-emitter voltage V
CE
(V)
DMC56402_I
O
-V
IN
Collector current I
C
(mA)
DMC56402_VIN-IO
V
CE(sat)
I
C
Collector-emitter saturation voltage V
CE(sat)
(V)
10
I
C
/ I
B
= 20
10
V
O
=
5 V
I
O
V
IN
100
V
IN
I
O
V
O
=
0.2 V
Output current I
O
(mA)
Input voltage V
IN
(V)
1
T
a
=
85°C
25°C
1
10
T
a
= −30°C
85°C
10
−1
−30°C
25°C
1
0.1
T
a
=
85°C
−30°C
25°C
10
−2
0.01
0.1
1
10
100
10
−3
0
0.5
1.0
1.5
2.0
0.1
0.1
1
10
100
Collector current I
C
(mA)
Input voltage V
IN
(V)
Output current I
O
(mA)
2
Ver. BED
