RN1961FS Overview

Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications

RN1961FS Parametric

Parameter Name	Attribute value
Maker	Toshiba Semiconductor
package instruction	SMALL OUTLINE, R-PDSO-F6
Contacts	6
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	BUILT-IN BIAS RESISTOR RATIO IS 1
Maximum collector current (IC)	0.05 A
Collector-emitter maximum voltage	20 V
Configuration	SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)	30
JESD-30 code	R-PDSO-F6
JESD-609 code	e0
Number of components	2
Number of terminals	6
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	NPN
Maximum power dissipation(Abs)	0.05 W
Certification status	Not Qualified
surface mount	YES
Terminal surface	TIN LEAD
Terminal form	FLAT
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON

Preview

Download Datasheet

View All

RN1961FS~RN1966FS

TOSHIBA Transistor

Silicon NPN Epitaxial Type (PCT process) (Bias Resistor built-in Transistor)

RN1961FS,RN1962FS,RN1963FS

RN1964FS,RN1965FS,RN1966FS

Switching, Inverter Circuit, Interface Circuit and

Driver Circuit Applications

1.0±0.05

0.1±0.05

0.8±0.05

0.1±0.05

0.15±0.05

Unit: mm

•

Two devices are incorporated into a fine pitch Small Mold (6 pin)

0.35 0.35

1.0±0.05

Incorporating a bias resistor into a transistor reduces parts count.

Reducing the parts count enable the manufacture of ever more

compact equipment and save assembly cost.

0.7±0.05

package.

0.1±0.05

Equivalent Circuit and Bias Resistor Values

Type No.

RN1961FS

RN1962FS

RN1963FS

RN1964FS

RN1965FS

RN1966FS

R1 (kΩ)

4.7

2.2

4.7

R2 (kΩ)

4.7

0.48

-0.04

+0.02

•

Complementary to RN2961FS~RN2966FS

fS6

JEDEC

JEITA

1.EMIITTER1

2.EMITTER2

3.BASE2

4.COLLECTOR2

5.BASE1

6.COLLECTOR1

(E1)

(E2)

(B2)

(C2)

(B1)

(C1)

―

2-1F1C

TOSHIBA

Weight: 0.001 g (typ.)

Absolute Maximum Ratings

(Ta = 25°C)

(Q1, Q2 common)

Characteristics

Collector-base voltage

Collector-emitter voltage

RN1961FS~

1966FS

RN1961FS~

1964FS

Emitter-base voltage

RN1965FS,

1966FS

Symbol

CBO

CEO

Rating

EBO

(Note 1)

stg

150

−55~150

°C

Unit

Equivalent Circuit

(top view)

Collector current

Collector power dissipation RN1961FS~

RN1966FS

Junction temperature

Storage temperature range

Note:

Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the

significant change in temperature, etc.) may cause this product to decrease in the reliability significantly

even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute

maximum ratings.

Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook

(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test

report and estimated failure rate, etc).

Note 1: Total rating

2007-11-01

RN1961FS Related Products

	RN1961FS	RN1962FS	RN1963FS	RN1964FS	RN1965FS	RN1966FS
Description	Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications	Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications	Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications	Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications	Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications	Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications
package instruction	SMALL OUTLINE, R-PDSO-F6	SMALL OUTLINE, R-PDSO-F6	SMALL OUTLINE, R-PDSO-F6	SMALL OUTLINE, R-PDSO-F6	SMALL OUTLINE, R-PDSO-F6	SMALL OUTLINE, R-PDSO-F6
Contacts	6	6	6	6	6	6
Reach Compliance Code	unknow	unknow	unknow	unknow	unknow	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 21.36	BUILT-IN BIAS RESISTOR RATIO IS 10
Maximum collector current (IC)	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A
Collector-emitter maximum voltage	20 V	20 V	20 V	20 V	20 V	20 V
Configuration	SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR	SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR	SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR	SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR	SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR	SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)	30	60	100	120	120	120
JESD-30 code	R-PDSO-F6	R-PDSO-F6	R-PDSO-F6	R-PDSO-F6	R-PDSO-F6	R-PDSO-F6
JESD-609 code	e0	e0	e0	e0	e0	e0
Number of components	2	2	2	2	2	2
Number of terminals	6	6	6	6	6	6
Maximum operating temperature	150 °C	150 °C	150 °C	150 °C	150 °C	150 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Polarity/channel type	NPN	NPN	NPN	NPN	NPN	NPN
Maximum power dissipation(Abs)	0.05 W	0.05 W	0.05 W	0.05 W	0.05 W	0.05 W
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	YES	YES	YES	YES	YES
Terminal surface	TIN LEAD	TIN LEAD	TIN LEAD	TIN LEAD	TIN LEAD	TIN LEAD
Terminal form	FLAT	FLAT	FLAT	FLAT	FLAT	FLAT
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
transistor applications	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
