RN2710JE,RN2711JE
TOSHIBA Transistor
Silicon PNP Epitaxial Type (PCT Process) (Bias Resistor Built-in Transistor)
RN2710JE, RN2711JE
Switching, Inverter Circuit, Interface Circuit and
Driver Circuit Applications
Unit: mm
•
Two devices are incorporated into an Extreme-Super-Mini (5-pin)
package.
•
Incorporating a bias resistor into a transistor reduces parts count.
•
Reducing the parts count enables the manufacture of ever more
compact
equipment and lowers assembly cost.
•
A wide range of resistor values are available for use in various circuit
designs.
•
Complementary to RN1710JE, RN1711JE
Equivalent Circuit and Bias Resistor Values
C
1.BASE1
(B1)
2.EMITTER
(E)
3.BASE2
(B2)
4.COLLECTOR2 (C2)
5.COLLECTOR1 (C1)
B
R1
JEDEC
JEITA
TOSHIBA
E
―
―
2-2P1D
Weight: 0.003g (typ.)
Absolute Maximum Ratings
(Ta = 25°C) (Q1, Q2 common)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
(Note 1)
T
j
T
stg
Rating
−50
−50
−5
−100
100
150
−55~150
Unit
V
V
V
mA
mW
°C
°C
Equivalent Circuit
(top view)
5
Q1
4
Q2
1
2
3
Note: Using continuously under heavy loads (e.g. the application of high
temperature/current/voltage and the significant change in temperature,
etc.) may cause this product to decrease in the reliability significantly
even if the operating conditions (i.e. operating
temperature/current/voltage, etc.) are within the absolute maximum
ratings.
Please design the appropriate reliability upon reviewing the Toshiba
Semiconductor Reliability Handbook (“Handling Precautions”/“Derating
Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 1:
Total rating
1
2007-11-01
RN2710JE,RN2711JE
Electrical Characteristics
(Ta = 25°C) (Q1, Q2 common)
Characteristics
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-emitter saturation voltage
Transition frequency
Collector output capacitance
Input resistor
RN2710JE
RN2711JE
Symbol
I
CBO
I
EBO
h
FE
V
CE (sat)
f
T
C
ob
R1
Test Condition
V
CB
= −50
V, I
E
=
0
V
EB
= −5
V, I
C
=
0
V
CE
= −5
V, I
C
= −1
mA
I
C
= −5
mA, I
B
= −0.25
mA
V
CE
= −10
V, I
C
= −5
mA
V
CB
= −10
V, I
E
=
0, f
=
1 MHz
⎯
Min
⎯
⎯
120
⎯
⎯
⎯
3.29
7
Typ.
⎯
⎯
⎯
−0.1
200
3
4.7
10
Max
−100
−100
400
−0.3
⎯
6
6.11
13
V
MHz
pF
kΩ
Unit
nA
nA
2
2007-11-01
