RN2966FS

Description
Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications
CategoryDiscrete semiconductor    The transistor
File Size166KB,8 Pages
ManufacturerToshiba Semiconductor
Websitehttp://toshiba-semicon-storage.com/
Download Datasheet Parametric Compare View All

RN2966FS Overview

Switching, Inverter Circuit, Interface Circuit and Driver Circuit Applications

RN2966FS Parametric

Parameter NameAttribute value
MakerToshiba Semiconductor
package instructionSMALL OUTLINE, R-PDSO-F6
Contacts6
Reach Compliance Codeunknow
ECCN codeEAR99
Maximum collector current (IC)0.05 A
Collector-emitter maximum voltage20 V
ConfigurationSEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)120
JESD-30 codeR-PDSO-F6
JESD-609 codee0
Number of components2
Number of terminals6
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Polarity/channel typePNP
Maximum power dissipation(Abs)0.05 W
Certification statusNot Qualified
surface mountYES
Terminal surfaceTIN LEAD
Terminal formFLAT
Terminal locationDUAL
transistor applicationsSWITCHING
Transistor component materialsSILICON
RN2961FS~RN2966FS
TOSHIBA Transistor
Silicon PNP Epitaxial Type (PCT process) (Bias Resistor built-in Transistor)
RN2961FS,RN2962FS,RN2963FS
RN2964FS,RN2965FS,RN2966FS
Switching, Inverter Circuit, Interface Circuit and
Driver Circuit Applications
1.0±0.05
0.1±0.05
0.8±0.05
0.1±0.05
0.15±0.05
Unit: mm
Two devices are incorporated into a fine pitch Small Mold (6 pin)
0.35 0.35
1.0±0.05
Incorporating a bias resistor into a transistor reduces parts count.
Reducing the parts count enable the manufacture of ever more
compact equipment and save assembly cost.
0.7±0.05
package.
1
2
3
6
5
4
0.1±0.05
Equivalent Circuit and Bias Resistor Values
C
Type No.
RN2961FS
RN2962FS
R2
RN2963FS
RN2964FS
E
RN2965FS
RN2966FS
R1 (kΩ)
4.7
10
22
47
2.2
4.7
R2 (kΩ)
4.7
10
22
47
47
47
0.48
-0.04
+0.02
Complementary to RN1961FS~RN1966FS
B
R1
fS6
JEDEC
JEITA
1.EMIITTER1
2.EMITTER2
3.BASE2
4.COLLECTOR2
5.BASE1
6.COLLECTOR1
(E1)
(E2)
(B2)
(C2)
(B1)
(C1)
2-1F1C
TOSHIBA
Weight: 0.001 g (typ.)
Absolute Maximum Ratings
(Ta = 25°C) (Q1, Q2 common)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Collector power dissipation
Junction temperature
Storage temperature range
RN2961FS~2966FS
RN2961FS~2966FS
RN2961FS~2964FS
RN2965FS, 2966FS
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
(Note 1)
T
j
T
stg
Rating
−20
−20
−10
−5
−50
50
150
−55~150
Unit
V
V
V
mA
mW
°C
°C
Equivalent Circuit
(top view)
6
5
4
Q1
Q2
1
2
3
Note:
Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 1: Total rating
1
2007-11-01
