7.6mmX7.6mm SUPER FLUX LED LAMP
AT T E N T I O N
W76761CVGC/H
GREEN
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Features
l
SUPER FLUX OUTPUT.
Description
l
DESIGN FOR HIGH CURRENT OPERATION.
l
OUTSTANDING MATERIAL EFFICIENCY.
l
RELIABLE AND RUGGED.
The Green source color devices are made with InGaN on
SiC Light Emitting Diode.
Static electricity and surge damage the LEDS.
It is recommended to use a wrist band or
anti-electrostatic glove when handling the LEDs.
All devices, equipment and machinery must be
electrically grounded.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAD2218
APPROVED: J. Lu
REV NO: V.2
CHECKED: Allen Liu
DATE: MAY/14/2003
DRAWN:L.ZHANG
PAGE: 1 OF 3
Selection Guide
P ar t N o .
W76761C VGC /H
GREEN (InGaN)
Dic e
L en s Ty p e
WATER C LEAR
Iv (m c d )
@ 20 m A *70m A
1800
Mi n .
3400
Ty p .
V i ew i n g
An g le
2θ1/2
20°
Notes:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. * Luminous intensity with asterisk is measured at 70mA.
3.Drive current between 10mA and 30mA are recommended for long term performance.
4.Operation at current below 10mA is not recommended.
GREEN (InGaN)
*5700
*13000
Electrical Maximum Ratings at T
A
=25°C
°
Sy m b o l
λ
p e a k
λ
D
∆λ
1/2
C
V
F
I
R
P ar am et er
Peak Wavelength
D omi nate Wavelength
Spectral Li ne Half-wi dth
C apaci tance
Forward Voltage
Reverse C urrent
Green
Green
Green
Green
Green
Green
D ev i c e
Ty p .
520
525
35
45
3.7
4.1
10
Max .
Un its
nm
nm
nm
pF
V
uA
Tes t C o n d i t i o n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power di ssi pati on
Gr een
120
150
-40
°
C To +85
°C
5
30
Un its
mW
mA
V
mA
Operati ng/Storage Temperature
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
Reverse Voltage
Peak Forward C urrent [1]
D C Forward C urrent
Lead Solder Temperature [2]
260
°
C For 5 Seconds
SPEC NO: DSAD2218
APPROVED: J. Lu
REV NO: V.2
CHECKED: Allen Liu
DATE: MAY/14/2003
DRAWN:L.ZHANG
PAGE: 2 OF 3
