VI-L03-CX: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 75W, Hybrid,; CategoryPower/power management The power supply circuit; File Size141KB，4 Pages; ManufacturerVICOR; Websitehttp://www.vicorpower.com/

Download Datasheet Parametric View All

VI-L03-CX Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	VI-L03-CX	-	-	View	Buy Now

VI-L03-CX Overview

DC-DC Regulated Power Supply Module, 1 Output, 75W, Hybrid,

VI-L03-CX Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	VICOR
Reach Compliance Code	not_compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	20 V
Minimum input voltage	10 V
Nominal input voltage	12 V
JESD-30 code	R-XDFM-P9
Maximum load regulation	0.2%
Number of functions	1
Output times	1
Number of terminals	9
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Maximum output voltage	26.4 V
Minimum output voltage	12 V
Nominal output voltage	24 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	75 W
Fine-tuning/adjustable output	YES

Preview

Download Datasheet

View All

1-800-735-6200

Mega Module &

Mega Module Jr.

Family

25 to 600 Watts

DC-DC Converters

Single, Dual,

Triple Output

Chassis Mount

Features

Inputs: 10 to 400Vdc

Any Output, 1 to 95Vdc

UL, CSA, TÜV, VDE, BABT

CE Marked

80-90% Efficiency (Typical)

Up to 27W/Cubic Inch

1 Up

2.58" x 2.5" x 0.62" (Junior)

4.9" x 2.5" x 0.62" (Full Size)

2 Up

2.58" x 4.9" x 0.62" (Junior)

4.9" x 4.9" x 0.62" (Full Size)

3 Up

2.58" x 7.3" x 0.62" (Junior)

4.9" x 7.3" x 0.62" (Full Size)

ZCS Power Architecture

Low Noise FM Control

Booster Versions Available for

Expanded Output Power-Full size only

Configuration Chart

Full-Size Modules

Mega Modules:

Single Output

VI-L

VI-M

VI-N

Dual Output

VI-P

VI-Q

Triple Output

VI-R

Junior-Size Modules

Mega Module Juniors:

Single Output

VI-LJ

Dual Output

VI-PJ

Triple Output

VI-RJ

50-200W

100-400W

300-600W

100-400W

150-600W

of Modules

4.9" x 2.5" x 0.62"

4.9" x 4.9" x 0.62"

4.9" x 7.3" x 0.62"

4.9" x 4.9" x 0.62"

4.9" x 7.3" x 0.62"

25-100W

50-200W

75-300W

2.58" x 2.5" x 0.62"

2.58" x 4.9" x 0.62"

2.58" x 7.3" x 0.62"

Input Voltage

Nominal

0 = 12V

1 = 24V

W= 24V

2 = 36V

3 = 48V

N = 48V

4 = 72V

T = 110V

5 = 150V

6 = 300V

7 = 150/300V

Range

Brownout Transient

10 - 20V

n/a

21 - 32V

18 - 36V

n/a

21 - 56V

42 - 60V

36 - 76V

n/a

55 - 100V

110

66 - 160V

n/a

100 - 200V

215

200 - 400V

170

425

100 - 375V

n/a

Output Voltage

Mega

Module Module Jr.

(4)

(1)

(8)

(5)

(8)

(5)

(6)

(1)

(10)

(5)

(10)

(5)

(9)

(4)

(8)

(5)

(9)

(5)

(10)

(6)

(5)

(1)

3.3V

10V

12V

15V

24V

28V

48V

(1 to 95V, consult factory)

Product Grade

Mega Module

-10°C to +85°C

-25°C to +85°C

-40°C to +85°C

-55°C to +85°C

Mega Module Jr.

-10°C to +100°C

-25°C to +100°C

-40°C to +100°C

-55°C to +100°C

Output Power/Current

Mega Module

OUT

≥

5V V

OUT

< 5V

Y = 50W Y = 10A

X = 75W X = 15A

W = 100W W = 20A

V = 150W V = 30A

U = 200W U = 40A

Mega Module Jr.

OUT

≥

5V V

OUT

< 5V

Z = 25W Z = 5A

Y = 50W Y = 10A

X = 75W X = 15A

W = 100W W = 20A

Product Highlights

Vicor’s Mega Module and Mega

Module Jr. Families of single, dual and

triple output DC-DC converters provide

power system designers with cost

effective, high performance, off-the-shelf

solutions to applications that might

otherwise require a custom supply.

Incorporating standard VI-200 or

VI-J00 Family converters in rugged,

chassis mount packages, Mega Module

and Mega Module Jr.’s can be ordered

with single, dual or triple outputs,

having a combined output power of up

to 600W. Totally isolated outputs

eliminate efficiency penalties and

output interaction problems.

Refers to Baseplate Temperature

Output Power/Current

OUT

≥

W = 100W

V = 150W

U = 200W

S = 300W

Q = 400W

OUT

< 5V

W =

20A

V =

30A

U =

40A

S =

60A

Q =

80A

Output Power/Current

OUT

≥

S = 300W

P = 450W

M = 600W

OUT

< 5V

= 60A

= 90A

M = 120A

Max. Output Per Module 5V Outputs >5V Outputs <5V Outputs

(1)

50W

10A

(4)

75W

15A

(5)

75W

100W

20A

(6)

100W

20A

*Brownout 75% of rated load.

**Transient voltage for 1 second.

***Consult factory for availability of “T” input Mega Module Jrs.

Max. Output Per Module

(7)

(8)

(9)

(10)

5V Outputs >5V Outputs <5V Outputs

100W

150W

30A

150W

30A

150W

200W

40A

200W

40A
