DC6M4/5/6 series
6 MHz DC/DC
step-down converter
Small, highly efficient switching converters
with ultra-low output voltage ripple
Ideal`for`mobile`and`battery`driven`devices,`the`DC6M4/5/6`series`combine`the`advantages`of`a`high`
frequency`DC/DC`buck`converter`with`high`performance`and`small`package`(1.0`mm`*`1.4`mm).`The`
6`MHz`switching`frequency`allows`use`of`inductors`as`small`as`470`nH`to`save`board`space.`Another`
key`advantage`is`the`ultra-low`output`voltage`ripple`performance`of`only`7`mV`(typ).
Key features
`
` Ultra-low`output`voltage`ripple`of`7`mV`(typ)
`
` Very`small`WLCSP6`package`for`board`space`reduction
`
` Optimized`for`load`range`of`40`mA`to`650`mA`with`an````
efficiency`of`up`to`95%
`
` Input`voltage`range`2.3`V`-`5.5`V
`
` Available`with`output`currents`of`425,`500,`650`mA
`
` Low`quiescent`current`of`0.2`µA`(typ)`in`shutdown
`
` Inrush,`short`circuit`&`temperature`protection
`
` Available`with`Auto/PWM`mode`select,`output`voltage``
select`or`power`good/XSHUTDOWN`option
Ultra-low output voltage ripple performance
30
V
ripple
(mVpp)
25
20
15
10
5
0
V
IN
= 4.2 V
V
IN
= 3.6 V
V
IN
= 3.0 V
Conversion efficiency
100
efficiency
(%)
80
60
40
20
0
DC6M601X6/285S
0
100
200
300
400
500
600
I
OUT
(mA)
700
Key applications
`
` Mobile`phones
`
` PC`tablets
`
` DSCs`(Digital`Still`Cameras)
`
` Video`cameras
`
` Game`pads
`
` Notebooks,`Netbooks,`and`Ultrabooks
NXPs`new`DC6M4/5/6`product`series`are`an`ideal`solution`for`
mobile`applications`and`battery`driven`devices.
`
0
100
200
300
400
500
600
I
OUT
(mA)
700
Selection guide
V
IN
(V)
Operation
frequency
(MHz)
Shutdown
current typ
(µA)
Output
voltage
ripple typ
(mV)
Efficiency
up to
(%)
I
OUT
(mA)
Output
voltage
V*
1.8
2.85
1.8`/`2.85
1.2
1.5
1.8
1.2`/`1.5
1.2`/`1.8
1.5`/`1.8
1.2
1.5
1.8
2.85`
1.2`/`1.5
1.2`/`1.8
1.5`/`1.8
DC6Mx01/xxxS
Modulation select
(Auto or forced PWM)
DC6M401X6/18S
DC6M401X6/285S
-
DC6M501X6/12S
DC6M501X6/15S
DC6M501X6/18S
-
-
-
DC6M601X6/12S
DC6M601X6/15S
DC6M601X6/18S
DC6M601X6/285S
-
-
-
DC6Mx02/xxxxxA
Voltage select
PWM/PFM Auto
Modulation
-
-
DC6M402X6/18285A
-
-
-
DC6M502X6/1215A
DC6M502X6/1218A
DC6M502X6/1518A
-
-
-
-
DC6M602X6/1215A
DC6M602X6/1218A
DC6M602X6/1518A
DC6Mx02/xxxxxF
Voltage select
Forced PWM
-
-
-
-
-
-
DC6M502X6/1215F
DC6M502X6/1218F
DC6M502X6/1518F
-
-
-
-
DC6M602X6/1215F
DC6M602X6/1218F
DC6M602X6/1518F
DC6Mx03/xxxA
XSHUTDOWN
PWM/PFM Auto
Modulation
-
-
-
DC6M503X6/12A
DC6M503X6/15A
DC6M503X6/18A
-
-
-
DC6M603X6/12A
DC6M603X6/15A
DC6M603X6/18A
-
-
-
-
425
500
2.3
-
5.5
6
0.2
7
95
650
*`Other`output`voltages`are`available`on`request
Three different operation mode versions can be ordered:
`
` DC6Mx01`-`Modulation`select:`automatic`pulse`frequency`modulation`(PFM)`/`pulse`width`modulation`(PWM)`or`forced`PWM`
mode`operation.`Selection`via`the`A1`MODE`pin.
`
` DC6Mx02`-`Output`voltage`select:`switch`between`2`different`output`voltages`V
OUT
,`e.g.`/1218`means`1.2`V`or`1.8`V`to`be`
selected`via`the`A1`MODE`pin.
`
` DC6Mx03`–`Power`good/XSHUTDOWN`output:`e.g.`enabling`a`camera`device`through`the`A1`pin.
WLCSP6 package
6 MHz
6 MHz frequency supports small inductors
frequency supports small inductors
6 MHz frequency supports small inductors
5.40mm.
Size: 1.36 x 0.96 x 0.47 mm
0.47±0.03
0.96
±0.05
A2
0.26
±0.05
A1
B1
C1
1.36
±0.05
Higher
Higher
Higher
frequency
frequency
frequency
3.70mm.
4.7µ
0603
4.7µ
0603
B2
C2
3 MHz
3 MHz
3 MHz
1008
1µ
DC3
Mxx
0.27
±0.02
0.2 ±0.02
0.4
±0.05
Side view
Bottom view
balls facing up
Smaller
Smaller
Smaller
inductor
inductor
inductor
Area: 20mm
2
Height: 2.5 mm
Area: 20mm
2
Height: 2.5mm
Area: 20mm
2
Height: 2.5 mm
4.05mm.
Package outline
6 MHz
6 MHz
6 MHz
A2`
B1`
B2`
C1`
C2`
V
IN
SW`
EN`
FB`
GND`
Supply`input`voltage`
Output`voltage`switch`regulator`
Enable`
Control`feedback`
Ground
Reduced
Reduced
Reduced
board space
board space
board space
3.05mm.
A1`
MODE`select
or`voltage`select
or`power`good`
Auto`moulation`or`forwed`PWM
output`voltage`1`or`voltage`2
high`if`power`good`
2.2µ
0402
DC6
Mxx
2.2µ
0402
0805
470n
Pinning
Area: 12mm Height: 1.0 mm
Comparison - typical inductor size vs. DC/DC frequency
Comparaison - typical inductor size vs. DC/DC frequency
Comparison - typical inductor size vs. DC/DC frequency
Area: 12mm Height: 1.0 mm
Area: 12mm
2
Height: 1.0mm
2
2
www.nxp.com
© 2012 NXP Semiconductors N.V.
All rights reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner. The
information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and
may be changed without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof
does not convey nor imply any license under patent- or other industrial or intellectual property rights.
Date of release: October 2012
Document order number: 9397 750 17340
Printed in the Netherlands
