CMDZ2V4_10

Description
SURFACE MOUNT SILICON ZENER DIODE 2.4 VOLTS THRU 47 VOLTS 250mW, 5% TOLERANCE
File Size360KB,2 Pages
ManufacturerCentral Semiconductor
Download Datasheet View All

CMDZ2V4_10 Overview

SURFACE MOUNT SILICON ZENER DIODE 2.4 VOLTS THRU 47 VOLTS 250mW, 5% TOLERANCE

CMDZ2V4 THRU CMDZ47V
SURFACE MOUNT
SILICON ZENER DIODE
2.4 VOLTS THRU 47 VOLTS
250mW, 5% TOLERANCE
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CMDZ2V4 Series
Zener Diode is a high quality voltage regulator in an
epoxy-molded
SUPERmini™
package, designed for
applications requiring low leakage.
MARKING CODE: SEE MARKING CODES ON
ELECTRICAL CHARACTERISTICS TABLE
SOD-323 CASE
MAXIMUM RATINGS:
(TA =50°C)
Power Dissipation
Operating and Storage Junction Temperature
SYMBOL
PD
TJ, Tstg
250
-65 to +175
UNIT
mW
°C
ELECTRICAL CHARACTERISTICS:
(TA=25°C), VF=0.9 MAX @ IF=10mA (FOR ALL TYPES)
ZENER
VOLTAGE
VZ @ IZT
MIN
CMDZ2V4
CMDZ2V6
CMDZ2V7
CMDZ3V0
CMDZ3V3
CMDZ3V6
CMDZ3V9
CMDZ4V3
CMDZ4V7
CMDZ5V1
CMDZ5V6
CMDZ6V2
CMDZ6V8
CMDZ7V5
CMDZ8V2
CMDZ9V1
CMDZ10V
CMDZ11V
CMDZ12V
CMDZ13V
V
2.28
2.47
2.57
2.85
3.14
3.42
3.71
4.09
4.47
4.85
5.32
5.89
6.46
7.12
7.79
8.65
9.50
10.45
11.40
12.35
NOM
V
2.4
2.6
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
MAX
V
2.52
2.73
2.84
3.15
3.47
3.78
4.10
4.52
4.94
5.36
5.88
6.51
7.14
7.88
8.61
9.56
10.50
11.55
12.60
13.65
TEST
CURRENT
IZT
mA
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
MAXIMUM
ZENER
IMPEDANCE
ZZT @ IZT
Ω
100
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
MAXIMUM
REVERSE
CURRENT
IR
μA
25
25
10
5.0
2.0
2.0
2.0
1.0
3.0
2.0
1.0
3.0
2.0
1.0
0.7
0.5
0.2
0.1
0.1
0.1
@ VR
V
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
4.0
4.0
5.0
5.0
6.0
7.0
8.0
8.0
8.0
2V4
2V6
2V7
3V0
3V3
3V6
3V9
4V3
4V7
5V1
5V6
6V2
6V8
7V5
8V2
9V1
10V
11V
12V
13V
TYPE
MARKING
CODE
R2 (8-January 2010)
