MS3128F20-16PY

Description
MIL Series Connector, 16 Contact(s), Aluminum Alloy, Male, Crimp Terminal, Receptacle
CategoryThe connector    The connector
File Size102KB,1 Pages
ManufacturerAmphenol
Websitehttp://www.amphenol.com/
Download Datasheet Parametric View All

MS3128F20-16PY Overview

MIL Series Connector, 16 Contact(s), Aluminum Alloy, Male, Crimp Terminal, Receptacle

MS3128F20-16PY Parametric

Parameter NameAttribute value
MakerAmphenol
Reach Compliance Codeunknown
Other featuresSTANDARD: MIL-C-26482, COMPATIBLE CONTACT: M39029/31-228
Back shell typeSOLID
Body/casing typeRECEPTACLE
Connector typeMIL SERIES CONNECTOR
Contact point genderMALE
Coupling typeBAYONET
DIN complianceNO
empty shellNO
Environmental characteristicsENVIRONMENT RESISTANT; MOISTURE RESISTANT
Filter functionNO
IEC complianceNO
MIL complianceYES
Manufacturer's serial numberMS3128F
Plug informationMULTIPLE MATING PARTS AVAILABLE
Mixed contactsNO
Installation typePANEL
OptionsGENERAL PURPOSE
Shell surfaceCADMIUM PLATED
Shell materialALUMINUM ALLOY
Housing size20
Termination typeCRIMP
Total number of contacts16
M.00 SE (MS3128)
wall mounting receptacle
TERMINATION ASSEMBLIES
MS / “E” Open Wire Seal
MS / “F” Strain Relief
MF00SE-XX-XXX
MS3128E-XX-XXX
To complete part number see how to order on page 32.
(MMC) located within .0025 of (TP)
Receptacle Front View
T
1
A Dia.
+.001
–.005
M
+.010
–.000
MF00SE-XX-XXX (SR)
MS3128F-XX-XXX
Receptacle Side View
Class MS / “E”
L
Max.
N
Max.
F
Min.
Class MS / “F”
G
Dia.
L
Max.
N
Max.
Shell
Size
R
R
1
S
Max.
T Dia.
±.005
Dia.
±.005
K
±.016
10
12
14
16
18
20
22
24
.719
.812
.906
.969
1.062
1.156
1.250
1.375
.812
.938
1.031
1.125
1.203
1.297
1.375
1.500
1.141
1.266
1.360
1.453
1.532
1.688
1.766
1.891
.120
.120
.120
.120
.120
.120
.120
.147
.150
.150
.150
.150
.150
.150
.150
.150
.590
.750
.875
1.000
1.125
1.250
1.375
1.500
.062
.062
.062
.062
.062
.094
.094
.094
.462
.462
.462
.462
.462
.556
.556
.589
1.328
1.328
1.328
1.328
1.328
1.359
1.359
1.422
.685
.813
.930
1.057
1.175
1.301
1.428
1.533
.297
.422
.547
.609
.734
.734
.922
.984
.188
.312
.375
.500
.625
.625
.750
.800
1.906
1.906
1.906
2.000
2.000
2.172
2.172
2.234
.891
1.016
1.141
1.203
1.469
1.469
1.656
1.750
All dimensions for reference only.
