D1F60
General Purpose Rectifiers
600V
1A
SOD-123
FEATURES
●
High
reliability with superior moisture
resistance
●
Applicable to Automatic Insertion
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
.
●Absolute Maximum Ratings (If not specified Tl=25℃)
Item
Symbol
Conditions
Storage Temperature
Tstg
Operating Junction Temperature
Tj
Maximum Reverse Voltage
V
RM
Average Rectified Forward Current
I
O
50Hz sine wave, R-load, On alumina substrate Ta=25℃
50Hz sine wave, R-load, On glass-epoxy substrate Ta=25℃
Peak Surge Forward Current
I
FSM
50Hz sine wave, Non-repetitive 1 cycle peak value, Tj=25℃
Ratings
-55∼150
150
600
1
0.75
25
Unit
℃
℃
V
A
A
●Electrical Characteristics (If not specified Tl=25℃)
Item
Symbol
Conditions
Forward Voltage
V
F
I
F
=1A, Pulse measurement
Reverse Current
I
R
V
R
=V
RM
, Pulse measurement
Thermal Resistance
Ratings
Max.1.1
Max.10
Unit
V
μA
θjl
junction to lead
θja
junction to ambient, On alumina substrate
junction to ambient, On glass-epoxy substrate
Max.23
Max.108 ℃/W
Max.157
E-mail: sales@taychipst.com
1 of 2
Web Site: www.taychipst.com
D1F60
General Purpose Rectifiers
600V
1A
RATINGS AND CHARACTERISTIC CURVES
D1F60
D1Fx
Forward Voltage
D1Fx
2
Forward Power Dissipation
SIN
Forward Power Dissipation P
F
[W]
10
1.5
Forward Current I
F
[A]
Tl=150°C [TYP]
1
Tl=25°C [TYP]
1
0.5
Pulse measurement per diode
0.1
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
0
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
Tj = 150°C
Sine wave
Forward Voltage V
F
[V]
Average Rectified Forward Current I
O
[A]
D1Fx
1.6
Average Rectified Forward Current I
O
[A]
Derating Curve
1.4
Average Rectified Forward Current I
O
[A]
D1Fx
Derating Curve
1.4
1.2
SIN
1
0.8
0.6
0.4
0.2
Alumina substrate
Soldering land 2mmφ
Conductor layer 20µm
Substrate thickness 0.64mm
1.2
Glass-epoxy substrate
Soldering land 2mmφ
Conductor layer 35µm
1
0.8 SIN
0.6
0.4
D1Fx
50
Peak Surge Forward Capability
I
FSM
0.2
0
0
20
40
60
80
100
120
140
160
10ms 10ms
0
Ambient Temperature Ta [°C]
40
1 cycle
0
20
40
60
80
100
120
140
160
V
R
= V
RM
Peak Surge Forward Current I
FSM
[A]
non-repetitive,
sine wave,
Tj=25°C before
surge current is applied
Ambient Temperature Ta [°C]
V
R
= V
RM
Sine wave
R-load
Free in air
I
O
0
0
V
R
t
p
D=t
p
/T
T
30
I
O
0
0
V
R
20
t
p
D=t
p
/T
T
10
0
1
2
5
10
20
50
100
Number of Cycles [cycles]
