BAT54T/AD/CD/SD/BR
200mW Surface Mount Schottky Barrier Diode
Small Signal Product
Features
◇
Fast switching speed
◇
Low forward voltage drop
◇
Moisture sensitivity level 1
◇
Matte Tin(Sn) lead finish with Nickel(Ni) underplate
◇
Pb free version and RoHS compliant
◇
Green compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code
SOT-363
Mechanical Data
◇
Case :SOT-363 small outline plastic package
◇
Terminal: Matte tin plated, lead free., solderable
per MIL-STD-202, method 208 guaranteed
◇
High temperature soldering guaranteed: 260°C/10s
◇
Weight : 0.006 gram (approximately)
Ordering Information (example)
Part No.
BAT54T
Package
SOT-363
Packing
3K / 7" Reel
Packing code
RF
Packing code
(Green)
RFG
Manufacture code
D0
Note : Detail please see "Ordering Information(detail, example)" below.
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Maximum Ratings
Parameter
Peak Repetitive Peak Reverse Voltage
Working Peak Reverse Voltage
DC Reverse Voltage
Forward Continuous Current
Repetitive Peak Forward Current
Forward Surge Current @ t < 1.0 s
Power Dissipation
Thermal resistance, junction to ambient air
Operating and Storage temperature
Electrical Characteristics
Symbol
V
RRM
V
RWM
V
R
I
F
I
FRM
I
FSM
P
d
R
θJA
T
j
, T
STG
Value
30
200
300
600
200
625
-65 to 150
Units
V
mA
mA
mA
mW
°C/W
o
C
Parameter
Reverse Breakdown Voltage
I
R
=100μA
I
F
=0.1mA
I
F
=1mA
Forward Voltage
I
F
=10mA
I
F
=30mA
I
F
=100mA
Reverse current
Total Capacitance
Reverse Recovery Time
V
R
=25V
V
R
=1V, f=1.0MHz
I
F
=I
R
=10mA, R
L
=100Ω, I
RR
=1mA
Symbol
V
(BR)
Min
30
--
--
Max
--
0.24
0.32
0.40
0.50
1
2.0
10
5.0
Units
V
V
F
--
--
--
V
I
R
C
T
t
rr
--
--
--
μA
pF
nS
Version : D13
Small Signal Product
RATINGS AND CHARACTERISTIC CURVES
Fig. 1 Forward Characteristics
1000
I
F
, Instantaneous Forward Current (A)
100.000
I
R
, Instantaneous Reverse Current (uA)
10.000
1.000
0.100
0.010
T
A
=0
o
C
0.001
0
10
20
30
T
A
=125
o
Fig. 2 Typical Reverse Characteristics
100
T
A
=125
o
10
T
A
=75
o
C
T
A
=25
o
C
1
T
A
=0
o
C
T
A
= -40
o
C
0.1
0.0
0.2
0.4
0.6
0.8
1.0
T
A
=75
o
C
T
A
=25
o
C
V
F
, Instantaneous Forward Voltage (V)
V
R
, Instantaneous Reverse Voltage (V)
Fig. 3 Capacitance Between Terminals Characteristics
Fig. 3
100
C
T
, Capacitance Between Terminals (pF)
Fig. 4 Power Derating Curve
10
P
D
, Power Dissipation (mW)
200
100
1
0
5
10
15
20
25
30
0
0
25
50
75
100
125
150
V
R
, Reverse Voltage (V)
T
A
, Ambient Temperature (°C)
Version : D13
Small Signal Product
Ordering information (Detail, example)
Part No.
BAT54xx
(Note 1)
BAT54T
BAT54T
Package
SOT-363
SOT-363
SOT-363
Packing
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
Packing code
Packing code
(Green)
RFG
RFG
RFG
D0
Manufacture code
RF
RF
RF
(Note 2)
Note 1："xx" is Device Code from "T" thru "BR"
Note 2： Manufacture special control, if empty means no special control requirement.
Tape & Reel specification
Item
Carrier width
Carrier length
Carrier depth
Sprocket hole
Reel outside diameter
Reel inner diameter
Feed hole width
Sprocket hole position
Punch hole position
Sprocket hole pitch
Embossment center
Overall tape thickness
Tape width
Reel width
Symbol
A
B
C
d
D
D1
D2
E
F
P0
P1
T
W
W1
Dimension(mm)
3.15 ±0.10
2.77 ±0.10
1.22 ±0.10
1.50 ± 0.10
178 ± 1
55 Min
13.0 ± 0.20
1.75 ±0.10
3.50 ±0.05
4.00 ±0.10
2.00 ±0.05
0.229 ±0.013
8.10 ±0.20
12.30 ±0.20
Version : D13
