FACTSHEET F-200
CPC2–108–B–02–SG–CU
CPC2 –116 – E– 03–SG
CPC2–110–B– 01– SG
CHIP PACKAGE
CPC2 SERIES
SPECIFICATIONS
Materials:
Insulator Material:
Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Operating Temp Range:
-65°C to +105°C with Tin;
-65°C to +125°C with Gold
Plating:
Au over 50µ"
(1,27µm) Ni
Current Rating:
Testing Now!
Max Processing Temp:
230°C for 60 seconds
SMT Lead Coplanarity:
(0,10mm) .004" max
ALSO AVAILABLE
Optional
lids for
chip/wire
bond
protection.
Robust
Phosphor Bronze
leads with soft
gold plating
Choice of cavity
up or down
Choice of
(0,64mm) .025"
or
(1,27mm) .050"
pitch
CPC2
1
NO. OF
POSITIONS
LEAD
PITCH
BODY
STYLE
Specify
BODY
STYLE
from
chart
PLATING
OPTION
OTHER
OPTION
–B
04, 08, 10, 16,
20, 24, 28
No. of positions x pitch / 2
+ (3,81) .150
No. of positions x
pitch / 2 + (1,50) .059
No. of positions
x pitch / 2
+ (0,08) .003
= (0,64mm)
.025" Pitch
–E
= (1,27mm)
.050" Pitch
= 30
µ
"
(0,76
µ
m)
Soft Gold
(.9999 pure)
–SG
Leave blank
for Cavity
Down
–CU
= Cavity
Up
–LDC
BODY
STYLE
–01
–02
–03
A
B
C
(3,81) (7,54) (9,68)
.150 .297 .381
(7,62) (11,35) (13,49)
.300 .447 .531
(12,70) (16,43) (18,57)
.500 .647 .731
= (1,52mm)
.060" thick
cupped
lid with
(0,76mm)
.030" cavity
–LDF
= (0,76mm)
.030" thick
flat lid
B
A
C
(0,71)
.028
TYP
(0,20)
.008
–CU Option
(Cavity up)
LEAD
PITCH
(1,14)
.045
(1,65)
.065
(0,81)
.032
D
(2,31)
.091
(2,79)
.110
D
(0,64)
.025
(1,27)
.050
–B
–E
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
Standard Option
(Cavity down)
SAMTEC USA
• Tel: 1-800-SAMTEC-9 or 812-944-6733 • Fax: 812-948-5047
SAMTEC UK
• Tel: 01236 739292 • Fax: 01236 727113
SAMTEC ASIA PACIFIC
• Tel: 65-745-5955 • Fax: 65-841-1502
SAMTEC GERMANY
• Tel: +49 (0) 89 / 89460-0 • Fax: +49 (0) 89 / 89460-299
SAMTEC FRANCE
• Tel: 01 60 95 06 60 • Fax: 01 60 95 06 61
SAMTEC ITALY
• Tel: 39 039 6890337 • Fax: 39 039 6890315
SAMTEC JAPAN
• Tel: 81-424-42-8318 • Fax: 81-424-42-8319
SAMTEC CHINA
• Tel: 86-21-5385-4089 • Fax: 86-21-5385-4047
SAMTEC TAIWAN
• Tel: (02) 2395-1677 • Fax: (02) 2395-1689
Due to technical progress, all designs, specifications and components are subject to change without notice.
