PSMN1R0-30YLC

Description
Power Field-Effect Transistor
CategoryDiscrete semiconductor    The transistor
File Size382KB,15 Pages
ManufacturerNexperia
Websitehttps://www.nexperia.com
Environmental Compliance
Download Datasheet Parametric Compare View All

PSMN1R0-30YLC Overview

Power Field-Effect Transistor

PSMN1R0-30YLC Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerNexperia
package instructionSMALL OUTLINE, R-PSSO-G4
Reach Compliance Codenot_compliant
ECCN codeEAR99
Other featuresHIGH RELIABILITY, ULTRA-LOW RESISTANCE
Avalanche Energy Efficiency Rating (Eas)259 mJ
Shell connectionDRAIN
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage30 V
Maximum drain current (ID)100 A
Maximum drain-source on-resistance0.0014 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JEDEC-95 codeMO-235
JESD-30 codeR-PSSO-G4
JESD-609 codee3
Humidity sensitivity level1
Number of components1
Number of terminals4
Operating modeENHANCEMENT MODE
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeN-CHANNEL
Maximum pulsed drain current (IDM)1030 A
surface mountYES
Terminal surfaceTin (Sn)
Terminal formGULL WING
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
