ISL59830AIAZ-T13 datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> Consumption circuit> ISL59830AIAZ-T13

ISL59830AIAZ-T13: Description3 CHANNEL, VIDEO AMPLIFIER, PDSO16, 0.150 INCH, ROHS COMPLIANT, PLASTIC, SSOP-16; CategoryAnalog mixed-signal IC Consumption circuit; File Size326KB，15 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Environmental Compliance

Download Datasheet Parametric View All

ISL59830AIAZ-T13 Overview

3 CHANNEL, VIDEO AMPLIFIER, PDSO16, 0.150 INCH, ROHS COMPLIANT, PLASTIC, SSOP-16

ISL59830AIAZ-T13 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Renesas Electronics Corporation
Parts packaging code	SOIC
package instruction	SSOP, SSOP16,.25
Contacts	16
Reach Compliance Code	compliant
ECCN code	EAR99
Nominal bandwidth	200000 kHz
Commercial integrated circuit types	VIDEO AMPLIFIER
JESD-30 code	R-PDSO-G16
JESD-609 code	e3
length	4.89 mm
Humidity sensitivity level	2
Number of channels	3
Number of functions	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Encapsulate equivalent code	SSOP16,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
power supply	3.3 V
Certification status	Not Qualified
Maximum seat height	1.73 mm
Maximum slew rate	150 mA
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
surface mount	YES
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn) - annealed
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	3.9 mm

Preview

Download Datasheet

View All

SI G N

W DE

OR N 9837

ED F

S L5

MME FER TO I

Data

GRADE

Sheet

R EC O

NOT PLEASE R PATIBLE

C OM

A PIN

F OR

ISL59830A

September 26, 2006

FN6233.3

True Single Supply Video Driver With

Power Down

The ISL59830A is a revolutionary device that allows true

single-supply operation of video amplifiers. The device runs

off a single 3.3V supply and generates the required negative

voltage internally. This allows for DC-accurate coupling of

video onto a 75Ω double-terminated line. Since the buffers

have an integrated 6dB gain, the only external components

required are the 75Ω termination resistors and a small

capacitor. An input reference voltage can be supplied to shift

the analog video level down by an amount equal to the

reference (typically 0.6V).

Features

• Triple single-supply buffer

• Operates from single +3.3V supply

• No output DC blocking capacitor needed

• Fixed gain of 2 output buffer

• Output three-statable

• Enable/disable function

• Charge pump power down function

• 50MHz 0.1dB bandwidth

• 200MHz -3dB bandwidth

Ordering Information

PART NUMBER

ISL59830AIAZ

(See Note)

PART

MARKING

59830AIAZ

TAPE

REEL

13”

PACKAGE

PKG.

DWG. #

• Pb-free plus anneal available (RoHS compliant)

Applications

• Driving video

16 Ld QSOP M16.15A

(Pb-free)

16 Ld QSOP M16.15A

(Pb-free)

ISL59830AIAZ-T7 59830AIAZ

(See Note)

Pinout

ISL59830A

(16 LD QSOP)

TOP VIEW

RIN 1

GIN 2

BIN 3

REF 4

VEE 5

GND 6

VEEOUT 7

DGND 8

16 ROUT

15 GOUT

14 BOUT

13 VCC

12 EN

11 VCC

10 PD

9 DVCC

NOTE: Intersil Pb-free plus anneal products employ special Pb-free

material sets; molding compounds/die attach materials and 100%

matte tin plate termination finish, which are RoHS compliant and

compatible with both SnPb and Pb-free soldering operations. Intersil

Pb-free products are MSL classified at Pb-free peak reflow

temperatures that meet or exceed the Pb-free requirements of

IPC/JEDEC J STD-020.

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 1-888-468-3774

Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.
