AMPMODU Interconnection System
Mod IV Wire-Applied Housings, Double-Row,
.100 x .100 [2.54 x 2.54] Centerline
Non-Polarized
.175
[4.45]
A
.100
Typ.
[2.54]
B
X
.240
[6.10]
.100
[2.54]
C
R
Optional
Material
Black thermoplastic, flame retardant
.050
[1.27]
Typ.
Related Product Data
Contacts
— pages 211-213
Mateable Headers and Posts
—
pages 96-99, 104, 105, 117-120
X
.070
[1.78]
Section X-X
.072
[1.83]
Mod IV Wire-Applied Housings
Technical Documents
—
pages 277, 278
Product Specification
108-25007, 108-25019, 108-25020,
108-25021
Application Specification
114-25003, 114-25016
No.
of
Pos.
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
48
50
52
54
56
58
60
64
66
70
72
Dimensions
A
.100
[2.54]
.200
[5.08]
.300
[7.62]
.400
[10.16]
.500
[12.70]
.600
[15.24]
.700
[17.78]
.800
[20.32]
.900
[22.86]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.300
[33.02]
1.400
[35.56]
1.500
[38.10]
1.600
[40.64]
1.700
[43.18]
1.800
[45.72]
1.900
[48.26]
2.000
[50.80]
2.100
[53.34]
2.200
[55.88]
2.400
[60.96]
2.500
[63.50]
2.600
[66.04]
2.700
[68.58]
2.800
[71.12]
2.900
[73.66]
3.000
[76.20]
3.200
[81.28]
3.300
[83.82]
3.500
[88.90]
3.600
[91.44]
B
—
.100
[2.54]
.200
[5.08]
.300
[7.62]
.400
[10.16]
.500
[12.70]
.600
[15.24]
.700
[17.78]
.800
[20.32]
.900
[22.86]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.300
[33.02]
1.400
[35.56]
1.500
[38.10]
1.600
[40.64]
1.700
[43.18]
1.800
[45.72]
1.900
[48.26]
2.000
[50.80]
2.100
[53.34]
2.300
[58.42]
2.400
[60.96]
2.500
[63.50]
2.600
[66.04]
2.700
[68.58]
2.800
[71.12]
2.900
[73.66]
3.100
[78.74]
3.200
[81.28]
3.400
[86.36]
3.500
[88.90]
5
Keying Plugs
Part No. 86286-1
(Plugs into standard or intermediate
pressure receptacle contact)
Material
— Natural color nylon
Part Nos.
C = .600 [15.24]
Stamped*
Unstamped**
—
5-87456-3
5-87456-0
4-87456-9
87456-2
87456-1
87456-4
87456-3
87456-6
87456-5
87456-8
87456-7
1-87456-0
87456-9
1-87456-2
1-87456-1
1-87456-4
1-87456-3
1-87456-6
1-87456-5
—
1-87456-7
2-87456-0
1-87456-9
2-87456-2
2-87456-1
2-87456-4
2-87456-3
2-87456-6
2-87456-5
2-87456-8
2-87456-7
3-87456-0
2-87456-9
3-87456-2
3-87456-1
—
3-87456-3
3-87456-6
3-87456-5
4-87456-4
4-87456-3
3-87456-8
3-87456-7
6-87456-0
5-87456-9
4-87456-0
3-87456-9
4-87456-2
4-87456-1
—
4-87456-5
—
6-87456-1
—
6-87456-3
5-87456-2
5-87456-1
6-87456-6
6-87456-5
5-87456-4
5-87456-7
—
5-87456-5
4-87456-8
4-87456-7
C = .645 [16.38]
Unstamped**
—
2-86177-5
1-86177-8
2-86177-0
1-86177-2
1-86177-3
1-86177-4
1-86177-5
1-86177-6
86177-1
86177-2
86177-3
86177-4
86177-5
86177-6
86177-7
86177-8
86177-9
1-86177-0
1-86177-1
—
1-86177-7
2-86177-3
2-86177-1
1-86177-9
—
—
—
—
—
—
2-86177-4
—
Part No. 87077-1
(for .645 high housings)
Part No. 87077-2
(for .600 high housings)
(Plugs directly into housing)
**Cavity
identification, part number and date code stamped on housing where size permits.
**No marking on housing.
Notes:
1. Strain reliefs are available and may be purchased separately. Consult Tyco Electronics.
Notes:
2. Contact
Extraction/Lance Reset Tool No. 843996-3.
Note:
All part numbers are RoHS compliant.
216
Catalog 1307819
Revised 8-08
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
