E_T-1W & F_T-1W Series
1W, FIXED INPUT, ISOLATED & UNREGULATED
DUAL/SINGLE OUTPUT DC-DC CONVERTER
RoHS
FEATURES
●
Small Footprint
●
SMD Package Style
●
3kVDC Isolation
●
Temperature Range: -40°C ~ +85°C
●
No Heatsink Required
●
Industry Standard Pinout
●
Internal SMD construction
●
No External Component Required
●
RoHS Compliance
PRODUCT PROGRAM
Input
Part
Number
F0303T-1W
F0305T-1W
E0305T-1W
E0312T-1W
F0505T-1W
F0509T-1W
F0512T-1W
F0515T-1W
3.3
3.0-3.6
Voltage (VDC)
Nominal
Range
Voltage
(VDC)
3.3
5
±5
±12
5
9
12
5
4.5-5.5
15
±5
±9
±12
±15
3.3
5
9
12
12
10.8-13.2
15
±5
±9
±12
±15
5
12
15
24
21.6-26.4
24
±5
±12
±24
Output
Current (mA)
Max.
304
200
±100
±42
200
110
84
66
±100
±55
±42
±33
303
200
110
84
66
±100
±55
±42
±33
200
84
66
42
±100
±42
±21
Min.
30
20
±10
±5
20
11
9
7
±10
±6
±5
±4
30
20
11
9
7
±10
±6
±5
±4
20
9
7
5
±10
±5
±3
73
75
68
77
70
76
78
79
71
77
78
79
70
69
73
73
74
71
73
74
75
69
77
74
76
70
77
79
UL
UL
UL
UL
UL
UL
UL
UL
UL
UL
UL
UL
UL
UL
UL
UL
Efficiency
Certificate
(%, Typ.)
APPLICATIONS
The E_T-1W & F_T-1W series are specially
designed for applications where a group of polar
power supplies are isolated from the input power
supply in a distributed power supply system on a
circuit board. These products apply to:
1) Where the voltage of the input power supply is
fixed (voltage variation
≤ ±10%);
2) Where isolation is necessary between input
and output (isolation voltage
≤3000VDC);
3) Where the regulation of the output voltage and
the output ripple noise are not demanding.
Such as: purely digital circuits, ordinary low
frequency analog circuits, and IGBT power device
driving circuits.
E0505T-1W
E0509T-1W
E0512T-1W
E0515T-1W
F1203T-1W
F1205T-1W
F1209T-1W
F1212T-1W
F1215T-1W
E1205T-1W
E1209T-1W
E1212T-1W
E1215T-1W
F2405T-1W
F2412T-1W
F2415T-1W
F2424T-1W
MODEL SELECTION
E2405T-1W
E2412T-1W
E2424T-1W
F0505T-1W
Rated Power
Package Style
Output Voltage
Input Voltage
Product Series
COMMON SPECIFICATIONS
Item
Storage humidity
Operating temperature
Storage temperature
-40
-55
15
1.5mm from case for 10 seconds
Test Conditions
Min.
Typ.
Max.
95
85
125
25
260
Free air convection
Epoxy Resin(UL94-V0)
1
3500
1.71
s
k hours
g
°C
Units
%
MORNSUN Science & Technology Co.,Ltd.
Address: No. 5, Kehui St. 1, Kehui development
center, Science Ave., Guangzhou Science City,
Luogang district, Guangzhou,P.R.China.
Tel: 86-20-28203030
Fax:86-20-38601272
Http://www.mornsun-power.com
Temp. rise at full load
Lead temperature
Cooling
Package material
Short circuit protection*
MTBF
Weight
*Supply voltage must be discontinued at the end of short circuit duration.
The copyright and authority for the interpretation of the products are reserved by Mornsun
Specifications subject to change without notice.
E_T-1W&F_T-1W
B/0-2010
Page 1 of 3
ISOLATION SPECIFICATIONS
Item
Isolation voltage
Isolation resistance
Test Conditions
Tested for 1 minute and 1mA max
Test at 500VDC
Min.
3000
1000
Typ.
Max.
Units
VDC
MΩ
TYPICAL CHARACTERISTICS
OUTPUT SPECIFICATIONS
Item
Output power
Line regulation
For Vin change of
±1%(3.3V
output)
For Vin change of
±1%(Others
output)
10% to 100% load (3.3V output)
10% to 100% load (5V output)
Load regulation
10% to 100% load (9V output)
10% to 100% load (12V output)
10% to 100% load (15V output)
10% to 100% load (24V output)
Output voltage accuracy
Temperature drift
Output ripple &Noise*
Switching frequency
100% full load
20MHz
Bandwidth
E_T-1W series
F_T-1W series
24V input
Others
15
12.8
8.3
6.8
6.3
Test Conditions
Min.
0.1
Typ.
Max.
1
±1.5
±1.2
20
15
10
10
10
%
Units
W
6.0
10
See tolerance envelope
graph
±0.03
%/°C
50
75
500
100
75
100
mVp-p
kHz
Operating Temp.(
o
C)
Full load, nominal input
*Test ripple and noise by
“parallel
cable” method. See detailed operation instructions at Testing of Power
Converter section, application notes.
RECOMMENDED REFLOW SOLDERING PROFILE
2 50
Te m p eratu r e (
o
C)
2 00
1 50
1 00
50
0
Ti me ( s ec .)
Remark: The curve applies only to the hot air reflow soldering
90 Se c Ma x
( >2 2 0
o
C )
26 0 C
1 0 S ec M ax
o
RECOMMENDED CIRCUIT
Dual Output
L
Vin
Cin
GND
Si ngl e Output
L
Vin
Cin
GND
L
+Vo
Cout
220 C
o
DC DC
L Cout
0V
-Vo
L
+Vo
DC DC
(Figure 1)
Cout
0V
APPLICATION NOTE
1) Requirement on output load
To ensure this module can operate efficiently and reliably, During operation, the minimum
output load
could not be less than 10% of the full load.
If the actual output power is very
small, please connect a resistor with proper resistance at the output end in parallel to
increase the load, or use our company’s products with a lower rated output power
(E _T-W2/F_T-W2 Series).
2) Recommended testing circuit
If you want to further decrease the input/output ripple, an
“LC”
filtering network may be
connected to the input and output ends of the DC/DC converter, see (Figure 1).
It should also be noted that the inductance and the frequency of the
“LC”
filtering network
should be staggered with the DC/DC frequency to avoid mutual interference. However, the
capacitance of the output filter capacitor must be proper. If the capacitance is too big, a
startup problem might arise. For every channel of output, provided the safe and reliable
operation is ensured, the greatest capacitance of its filter capacitor sees (Table 1).
3) Output Voltage Regulation and Over-voltage Protection Circuit
The simplest device for output voltage regulation, over-voltage and over-current
protection is a linear voltage regulator with overheat protection that is connected to the input
or output end in series (Figure2).
4) Overload Protection
Under normal operating conditions, the output circuit of these products has no protection
against overload. The simplest method is to connect a self-recovery fuse in series at the
input end or add a circuit breaker to the circuit.
5) No parallel connection or plug and play
The copyright and authority for the interpretation of the products are reserved by Mornsun
GND
S ingle O utput
Vi n
GND
R EG
Dual O u tput
Vi n
R EG
REG
+Vout
0V
DC DC
REG
-Vout
REG
+Vout
DC DC
0V
(Figure2)
EXTERNAL CAPACITOR TABLE (Table 1)
Vin
Cin Single Cout
Dual Cout
Vout
(µF)
(µF)
(VDC) (µF)
Vout
(VDC)
(VDC)
3.3/5
4.7
5
10
±3.3/5
4.7
12
24
-
2.2
1
-
9
12
15
24
4.7
2.2
1
0.47
±9
±12
±15
±24
2.2
1
1
0.47
It’s not recommended to connect any external
capacitor in the application field with less than 0.5 watt
output.
Specifications subject to change without notice.
E_T-1W&F_T-1W
B/0-2010
Page 2 of 3
OUTLINE DIMENSIONS & FOOTPRINT DETAILS
MECHANICAL DIMENSIONS
RECOMMENDED FOOTPRINT
(Side View)
6.50 [0.256]
6.25 [0.246]
1.00 [0.039]
0.25 [0.010]
15.24 [0.600]
12.70 [0.500]
2.54 [0.100]
0.60 [0.024]
12 11 10
10.10 [0.398]
1
2
3
5
6
2.10 [0.083]
8
7
2.54 [0.100]
12 11 10
7.50 [0.295]
1 2
3
8
5
7
11.20 [0.441]
6
2.54 [0.100]
(Top View)
A
0.25 [0.010]
A
8.50 [0.335]
1.35 [0.053]
5°max
FOOTPRINT DETAILS
Single
Pin
Dual
1
GND
GND
2
Vin
Vin
5
0V
0V
6
NC
-Vo
+Vo
+Vo
8
Others
NC
NC
NC:No Connection
Note:
Unit: mm[inch]
Pin section tolerances: 0.10mm[ 0.004inch]
General tolerances: 0.25mm[ 0.010inch]
TUBE OUTLINE DIMENSIONS
REEL PACKING OUTLINE DIMENSIONS
Taping dimension:
∅1.50
[0.059]
2.00 [0.079]
1.75 [0.069]
11.50 [0.453]
0.50 [0.020]
14.10 [0.555]
8.90 [0.350]
15.65[0.616]
7.40 [0.291]
6.50 [0.256]
11.60 [0.457]
4.30 [0.169]
0.60 [0.024]
14.10 [0.555]
16.00[0.630]
∅1.50
[0.059]
24.00 [0.945]
7.35 [0.289]
Taping reel dimension:
29.40 [1.157]
∅100.00
[3.937]
Note:
Unit: mm[inch]
General tolerances:
0.5mm[
0.020inch]
L=540mm[21.260inch] Devices per tube quantity : 33pcs
L=220mm[8.661inch] Devices per tube quantity : 12pcs
∅13.00
[0.512]
∅21.50
[0.846]
Note:
Unit: mm[inch]
General tolerances: 0.5mm[ 0.020inch]
Devices per reel quantity: 500pcs
Note:
1. Operation under minimum load will not damage the converter; However, they may not meet all specification listed, and that will reduce the
life of product.
2. All specifications measured at Ta=25°C, humidity<75%, nominal input voltage and rated output load unless otherwise specified.
1. Only typical models listed, other models may be different, please contact our technical person for more details.
2. In this datasheet, all the test methods of indications are based on corporate standards.
The copyright and authority for the interpretation of the products are reserved by MORNSUN
Specifications subject to change without notice.
E_T-1W&F_T-1W
B/0-2010
Page 3 of 3
