KBL401G-KBL407G
Single Phase 4.0AMP. Glass Passivated Bridge Rectifiers
KBL
Features
Glass passivated junction
Ideal for printed circuit board
Reliable low cost construction
High surge current capability
High temperature soldering guaranteed:
o
260 C / 10 seconds / 0.375” ( 9.5mm )
lead length at 5 lbs. ( 2.3 Kg ) tension
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
A
= 50
o
C
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 2.0A
@ 4.0A
Symbol
KBL KBL KBL KBL KBL KBL KBL
401G 402G 403G 404G 405G 406G 407G
Units
V
V
V
A
A
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
50
35
50
100
70
100
200
140
200
400
280
400
4.0
150
600
420
600
800
560
800
1000
700
1000
1.0
V
1.1
o
10
uA
Maximum DC Reverse Current @ T
A
=25 C
I
R
o
at Rated DC Blocking Voltage @ T
A
=125 C
500
uA
Typical Thermal Resistance (Note)
R
θJA
19
o
C/W
2.4
R
θJL
o
Operating Temperature Range
T
J
-55 to +150
C
o
Storage Temperature Range
T
STG
-55 to +150
C
Note: Thermal Resistance from Junction to Ambient and from Junction to Lead Mounted on P.C.B.
With 0.6” x 0.6”” (16mm x 16mm) Copper Pads.
http://www.luguang.cn
mail:lge@luguang.cn
KBL401G-KBL407G
Single Phase 4.0AMP. Glass Passivated Bridge Rectifiers
RATINGS AND CHARACTERISTIC CURVES (KBL401G THRU KBL407G)
FIG.1- MAXIMUM FORWARD CURRENT DERATING
CURVE
5
100
FIG.2- TYPICAL REVERSE CHARACTERISTICS
PER BRIDGE ELEMENT
AVERAGE FORWARD CURRENT. (A)
4
3
INSTANTANEOUS REVERSE CURRENT. ( A)
TJ=125
0
C
10
2
1
0
0
50
100
o
AMBIENT TEMPERATURE. ( C)
150
1
TJ=25
0
C
FIG.3- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT PER BRIDGE ELEMENT
250
PEAK FORWARD SURGE CURRENT. (A)
0.1
0
200
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE. (%)
FIG.4- TYPICAL JUNCTION CAPACITANCE
150
1000
600
JUNCTION CAPACITANCE.(pF)
100
500
Tj=25
0
C
50
400
300
200
100
0
0.1
0
1
100
10
NUMBER OF CYCLES AT 60Hz
1000
10
FIG.5- TYPICAL FORWARD CHARACTERISTICS
PER BRIDGE ELEMENT
0.5
1
2
5
10
20
50 100
200
500 800
REVERSE VOLTAGE. (V)
INSTANTANEOUS FORWARD CURRENT. (A)
1
0.1
Tj=25 C
PULSE WIDTH-300 S
1% DUTY CYCLE
0.01
0.4
0
0.6
0.8
1.0
1.2
1.4
INSTANTANEOUS FORWARD VOLTAGE. (V)
1.6
http://www.luguang.cn
mail:lge@luguang.cn
Version: A06
