SURFACE MOUNT DISPLAY
P/N: KCSA03-106
SUPER BRIGHT ORANGE
Features
0.3 INCH DIGIT HEIGHT.
LOW CURRENT OPERATION.
EXCELLENT CHARACTER APPEARANCE.
I.C. COMPATIBLE.
MECHANICALLY RUGGED.
GRAY FACE,WHITE SEGMENT.
PACKAGE : 550PCS / REEL.
MOISTURE SENSITIVITY LEVEL : LEVEL 4.
RoHS COMPLIANT.
Description
The Super Bright Orange source color devices are made
with DH InGaAlP on GaAs substrate Light Emitting Diode.
Package Dimensions & Internal Circuit Diagram
Notes:
1. All dimensions are in millimeters (inches), Tolerance is
±0.25(0.01")unless
otherwise noted.
2. Specifications are subject to change without notice.
3.The gap between the reflector and PCB shall not exceed 0.25mm
SPEC NO: DSAF8557
APPROVED: J. Lu
REV NO: V.3
CHECKED: Joe Lee
DATE: MAR/28/2006
DRAWN: Y.L.LI
PAGE: 1 OF 4
Selection Guide
Part No.
Dice
Lens Type
Iv (ucd) [1]
@ 10mA
Min.
KCSA03-106
SUPER BRIGHT ORANGE (InGaAlP)
WHITE DIFFUSED
4700
Typ.
21371
Common Anode, Rt.
Hand Decimal.
Description
Note:
1
.Luminous Intensity/ Luminous Flux: +/-15%.
Electrical / Optical Characteristics at T
A
=25°C
Symbol
λpeak
λD[1]
∆λ1/2
C
V
F
[2]
I
R
Parameter
Peak Wavelength
Dominant Wavelength
Spectral Line Half-width
Capacitance
Forward Voltage
Reverse Current
Device
Super Bright Orange
Super Bright Orange
Super Bright Orange
Super Bright Orange
Super Bright Orange
Super Bright Orange
Typ.
610
601
29
15
2.1
2.5
10
Max.
Units
nm
nm
nm
pF
V
uA
Test Conditions
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Notes:
1.Wavelength: +/-1nm
2.Forward Voltage: +/-0.1V
Absolute Maximum Ratings at T
A
=25°C
Parameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Note:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
Super Bright Orange
75
30
195
5
-40°C To +85°C
Units
mW
mA
mA
V
SPEC NO: DSAF8557
APPROVED: J. Lu
REV NO: V.3
CHECKED: Joe Lee
DATE: MAR/28/2006
DRAWN: Y.L.LI
PAGE: 2 OF 4
