KBPC15005(W)-KBPC1510(W)
Silicon Bridge Rectifiers
VOLTAGE RANGE: 50 --- 1000 V
CURRENT: 15.0 A
KBPC-W
Features
Surge overload rating to
300
Am peres peak
Ideal for printed circuit board
Reliable low cost construction utilizing m olded
φ
φ
1 .1± 0.1
28.6± 0.6
TY
P
.
5
.9
20.5± 0.5
17.5± 0.5
17.5± 0.5
12.7± 0.5
plastic technique results in inexpensive product
Lead solderable per MIL-STD-202 m ethod 208
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
ambient tem perature unless otherwise specified.
Single phase,half wave,60 Hz,resistive or inductive load. For capacitive load,derate by 20%.
KBPC KBPC KBPC KBPC KBPC KBPC KBPC
15005 1501 1502 1504 1506 1508 1510 UNITS
(W)
(W)
(W)
(W)
(W)
(W)
(W)
Maximum recurrent peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forw ard
Output current
@T
A
=25
28.6± 0.6
11.2± 0.3
Rating to 1000V PRV
V
RRM
V
RMS
V
DC
I
F(AV)
50
35
50
100
70
100
200
140
200
400
280
400
15.0
600
420
600
800
560
800
1000
700
1000
V
V
V
A
Peak forw ard surge current
8.3ms single half-sine-w ave
superimposed on rated load
Maximum instantaneous forw ard voltage
@ 7.5 A
Maximum reverse current
at rated DC blocking voltage
@T
A
=25
@T
A
=100
I
FSM
300.0
A
V
F
I
R
T
J
T
STG
1.1
10.0
1.0
- 55 ---- + 125
- 55 ---- + 150
V
μA
mA
Operating junction temperature range
Storage temperature range
http://www.luguang.cn
mail:lge@luguang.cn
KBPC15005(W)-KBPC1510(W)
Silicon Bridge Rectifiers
Ratings AND Charactieristic Curves
FIG.1 -- PEAK FORWARD SURGE CURRENT
AVERAGE FORWARD OUTPUT CURRENT,
AMPERES
PEAK FORWARD SURGE CURRENT,
FIG.2 -- FORWARD DERATING CURVE
500
25
400
8.3ms Single Half Sine Wave
T
J
=125
20
AMPERES
300
15
200
10
100
5
0
1
10
100
0
0
50
100
150
NUMBER OF CYCLES AT 60H
Z
AMBIENT TEMPERATURE,
FIG.3 -- TYPICAL FORWARD CHARACTERISTIC
FIG.4 -- TYPICAL REVERSE CHARACTERISTIC
INSTANTANEOUS FORWARD CURRENT,
AMPERES
100
INSTANTANEOUS REVERSE CURRENT,
MICRO AMPERES
10
10
1.0
1.0
0.1
T
J
=25
0.1
.01
.01
.2
0
20
40
60
80
100
120
140
.4
.6
.8
1.0
1.2
1.4
1.6
PERCENT OF RATED PEAK REVERSE VOLTAGE
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
http://www.luguang.cn
mail:lge@luguang.cn
