TDK MLCC US Catalog
Page 290
Version B11
CGA Series
Automotive Grade Capacitors
Type: CGA2 (C1005), CGA3 (C1608),
CGA4 (C2012), CGA5 (C3216), CGA6 (C3225)
•
•
•
•
•
•
Features
• The CGA series consists of products that can be used
for the power train, safety equipment, etc. of a vehicle
• Qualified to AEC Q200 test standard
• Parts are manufactured using tested and stable
manufacturing processes and are subjected to
increased inspections to guarantee a higher level of
reliability
• A monolithic structure ensures superior mechanical
strength and reliability
• Available in X8R temperature characteristic for up to
150ºC operating temperature
• High capacitance has been achieved through
precision technologies that enable the use of multiple
thinner ceramic dielectric layers
• High-accuracy automatic mounting is facilitated
through the maintenance of very precise dimensional
tolerances
• Low stray capacitance ensures high conformity with
nominal values, thereby simplifying the circuit design
process
Applications
Automotive applications
High reliability requirement applications
Harsh environment requirement application
Smart meter
Base stations
Noise bypass in automotive
Shape &
Dimensions
L
W
T
B
Body Length
Body Width
Body Height
Terminal Width
Dimensions in mm
Part Number
Construction
CGA 5 L 2 X8R 1E 105 K T XXXX
Series Name
Dimensions L x W (mm)
Symbol
2
3
4
5
6
Symbol
B
C
E
F
H
J
Symbol
1
2
Length
1.00
±
0.05
1.60
±
0.10
2.00
±
0.20
3.20
±
0.20
3.20
±
0.40
Thickness
0.50 mm
0.60 mm
0.80 mm
0.85 mm
1.15 mm
1.25 mm
Condition
1
×
R.V.
2
×
R.V.
Width
0.50
±
0.05
0.80
±
0.10
1.25
±
0.20
1.60
±
0.20
2.50
±
0.30
Symbol
K
L
M
N
P
Thickness
1.30 mm
1.60 mm
2.00 mm
2.30 mm
2.50 mm
Internal Codes
Packaging Style
Capacitance Tolerance
Tolerance Code
C
D
J
K
M
Packaging Code
T
Style
Tape & Reel
Thickness T (mm)
Voltage Condition for Life Test
Symbol
3
4
Condition
1.5
×
R.V.
1.2
×
R.V.
Temperature
Range
-55 to +125ºC
-55 to +85ºC
-55 to +125ºC
-55 to +125ºC
-55 to +125ºC
-55 to +150ºC
Nominal Capacitance (pF)
The capacitance is expressed in three digit codes and
in units of pico Farads (pF). The first and second digits
identify the first and second significant figures of the
capacitance. The third digit identifies the multiplier.
R designates a decimal point.
Capacitance Code
0R5
010
102
105
Capacitance
0.5pF
1pF
1,000pF (1nF)
1,000,000pF (1µF)
Voltage Code
1H
2A
2E
2W
2J
Voltage (DC)
50V
100V
250V
450V
630V
Tolerance
± 0.25 pF
± 0.50 pF
±
5%
±
10%
±
20%
Temperature Characteristic
Temperature
Characteristics
C0G
X5R
X7R
X7S
X7T
X8R
Capacitance
Change
0±30 ppm/ºC
±
15%
±
15%
±
22%
+22/-33%
±
15%
Rated Voltage (DC)
Voltage Code
0J
1A
1C
1E
1V
Voltage (DC)
6.3V
10V
16V
25V
35V
TDK MLCC US Catalog
Page 291
Version B11
Capacitance
Range Chart
Capacitance Range Chart
Temperature Characteristics: X7R (± 15%), X7S (± 22%), X8R (±15%)
Rated Voltage: 100V (2A), 50V (1H), 35V (1V), 25V (1E), 16V (1C), 10V (1A)
Capacitance
(pF)
150
220
330
470
680
1,000
1,500
2,200
3,300
4,700
6,800
10,000
15,000
22,000
33,000
47,000
68,000
100,000
220,000
Cap
Code
151
221
331
471
681
102
152
222
332
472
682
103
153
223
333
473
683
104
224
X7R
Tolerance
K: ± 10%
1H
(50V)
1V
(35V)
1E
(25V)
1C
(16V)
1A
(10V)
CGA2 [EIA CC0402]
X7S
2A
(100V)
1H
(50V)
X8R
1E
(25V)
Standard Thickness
0.50 mm
TDK MLCC US Catalog
Page 293
Version B11
