Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR4010CTNA
SSR4010CTPA
40 AMP, 100 VOLTS
SCHOTTKY RECTIFIER
Designer’s Data Sheet
Part Number/Ordering Information
1/
SSR4010
__ __ __ __
│ │ │
└
Screening
2/
__
= Not Screened
│ │ │
TX = TX Level
│ │ │
TXV = TXV
│ │ │
S = S Level
│ │ │
│ │
└
Lead Options
__ = Straight Leads,
D = Bent Down, U = Bent Up
│ │
│
└
Package
NA = TO-258 w/ .040” Dia. Legs
│
PA = TO-259 w/ .040” Dia. Legs
│
N = TO-258 w/ .060” Dia. Legs
│
P = TO-259 w/ .060” Dia. Legs
│
└
Configuration
CT = Common Cathode,
CA = Common Anode, D = Doubler,
DR = Reverse Doubler
FEATURES:
•
•
•
•
•
•
•
•
•
•
PIV 100 Volts
Low Forward Voltage Drop
Low Reverse Leakage Current
Isolated Hermetically Sealed Power Package
Ceramic Seal Package Available
Custom Lead Forming Available
Guard Ring for Overvoltage Protection
Gold Eutectic Die Attach
175
°
C Operating Junction Temperature
TX, TXV, or Space Level Screening Available
MAXIMUM RATINGS
RATING
Peak Repetitive Reverse Voltage and DC
Blocking Voltage
SSR4010CTNA, SSR4010CTPA
Average Rectified Output Current
(Resistive Load, 60Hz, Sine Wave, TA=25
°
C)
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, superimposed on I
O
,
allow junction to reach equilibrium between pulses,
TA=25
°
C)
Operating and Storage Temperature
Maximum Thermal Resistance
Junction to Case
3/
Junction to Case (Per Leg)
NOTES:
1/
2/
3/
.
4/
3/ 4/
3/ 4/
SYMBOL
V
RRM
V
RWM
V
R
I
O
I
FSM
VALUE
100
UNIT
Volts
40
400
Amps
Amps
T
OP
& T
STG
R
θJC
-65 to +175
0.6
1.2
TO-258
TO-259
°
°
C
C/W
For ordering information, price, and availability- Contact Factory
Screened to MIL-PRF-19500.
Both Legs Tied Together.
Doubler: I
O
= 20A, I
FSM
= 200A.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0099F
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR4010CTNA
SSR4010CTPA
ELECTRICAL CHARACTERISTICS (Per Leg)
CHARACTERISTICS
Instantaneous Forward Voltage Drop
(I
F
= 10 A, T
A
= 25
°
C, Pulse)
(I
F
= 15 A, T
A
= 25
°
C, Pulse)
(I
F
= 20 A, T
A
= 25
°
C, Pulse)
Instantaneous Forward Voltage Drop
(I
F
= 10 A, T
A
= -55
°
C, Pulse)
Reverse Leakage Current
(Rated V
R
, T
A
= 25
°
C, Pulse)
Reverse Leakage Current
(Rated V
R
, T
A
= 100
°
C, Pulse)
Junction Capacitance
(V
R
= 10 V, T
A
= 25
°
C, f = 1 MHz)
SYMBOL
V
F1
V
F2
V
F3
V
F4
I
R1
I
R2
C
J
MAXIMUM
0.75
0.82
0.85
0.84
200
10
800
UNIT
Vdc
Vdc
µA
mA
pF
TO-258 (N Suffix)
TO-259 (P Suffix)
Optional Bent Down Leads
(D Suffix)
Optional with Bent Up Leads
(U Suffix)
Pin Assignment
For information on curves, contact the Factory Representative for Engineering
Assistance.
Code
CT
CA
D
DR
Function
Common
Cathode
Common
Anode
Doubler
Reverse
Doubler
Pin 1
Anode
Cathode
Cathode
Anode
Pin 2
Cathode
Anode
Common
Common
Pin 3
Anode
Cathode
Anode
Cathode
