BR25005-BR2510
Silicon Bridge Rectifiers
VOLTAGE RANGE: 50 --- 1000 V
CURRENT: 25.0 A
BR
Features
Rating to 1000V PRV
Surge overload rating to
300
Amperes peak
Ideal for printed circuit board
Reliable low cost construction utilizing molded
METAL HEAT SINK
28.6± 0.45
16± 0.5
Lead solderable per MIL-STD-202 method 208
Mounting: thru hole for # 8 screw
mounting
13.7± 0.5
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
ambient temperature unless otherwise specified.
Single phase,half wave,60 Hz,resistive or inductive load. For capacitive load,derate by 20%.
BR
25005
Maximum recurrent peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forw ard
output current
@T
A
=50
BR
2501
100
70
100
BR
2502
200
140
200
BR
2504
400
280
400
25.0
BR
2506
600
420
600
BR
2508
800
560
800
16.2± 0.5
6.4 0.8
28.5± 0.3
18± 0.6
plastic technique results in inexpensive product
φ
5.3 TYP.
11.2± 0.2
PLASTIC
12.2± 0.5
BR
2510
1000
700
1000
UNITS
V
V
V
A
V
RRM
V
RMS
V
DC
I
F(AV)
50
35
50
Peak forw ard surge current
8.3ms single half-sine-w ave
superimposed on rated load
Maximum instantaneous forw ard voltage
at
12.5A
Maximum reverse current
at rated DC blocking voltage
@T
A
=25
@T
A
=100
I
FSM
300.0
A
V
F
I
R
T
J
T
STG
1.1
5.0
0.5
- 55 ---- + 150
- 55 ---- + 150
V
μ
A
mA
Operating junction temperature range
Storage temperature range
http://www.luguang.cn
mail:lge@luguang.cn
BR25005-BR2510
Silicon Bridge Rectifiers
Ratings AND Charactieristic Curves
FIG.1 -- PEAK FORWARD SURGE CURRENT
AVERAGE FORWARD OUTPUT CURRENT,
AMPERES
FIG.2 -- FORWARD DERATING CURVE
PEAK FORWARD SURGE CURRENT,
AMPERES
500
25
400
8.3ms Single Half Sine Wave
T
J
=125
20
300
15
200
10
100
5
0
0
0
50
100
150
175
1
10
100
NUMBER OF CYCLES AT 60H
Z
AMBIENT TEMPERATURE,
FIG.3 -- TYPICAL FORWARD CHARACTERISTIC
FIG.4 -- TYPICAL REVERSE CHARACTERISTIC
10
INSTANTANEOUS FORWARD CURRENT,
AMPERES
10
INSTANTANEOUS REVERSE CURRENT,
MICRO AMPERES
100
1.0
1.0
T
J
=25
0.1
0.1
T
J
=25
.01
0
20
40
60
80
100
120
140
.01
.6
.7
.8
.9
1
1.1
1.2
1.3
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
PERCENT OF RATED PEAK REVERSE VOLTAGE
http://www.luguang.cn
mail:lge@luguang.cn
