Customer Specification

PART NO. B951034

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Cond

1

2) Cable Assembly

a) Twists:

b) Core Wrap

3) Shield:

a) Drain Wire

b) Braid

4) Jacket

a) Color(s)

b) Ripcord

Color

BLACK

3 X 1 COND

28 (7/36) AWG TC

0.010" Wall, Nom. PVC, Semi Rigid

Alpha Wire Color Code E

Cond

2

3 Components Cabled

13.7 Twists/foot (min)

Clear Mylar Tape, 25% Overlap, Min.

A/P/A Tape, 25% Overlap, Min.

28 (7/36) AWG TC

TC,70% Coverage, Min.

0.032" Wall, Nom.,PVC

GREY

1 End 810 Denier Nylon

ALPHA WIRE-* P/N B951034

0.09MM2 (28AWG) (UL) TYPE CM 105C OR AWM 2464

VW-1 --- LLXXXXXX CSA 105C TYPE CMG FT4 CE

ROHS (SEQ METERS)

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

0.171 (0.181 Max.)

Color

BROWN

Cond

3

Color

RED

0.015

0.035

c) Print

Applicable Specifications

1) UL

a) Component 1

b) Overall

AWM/STYLE 10002

AWM/STYLE 2464

CM

VW-1

2) CSA International

CMG

FT4

3) IEC

EN 60332-1 Flame Behavior

EN 60332-2 Flame Behavior

4) CE:

EU Low Voltage Directive 2006/95/EC

105°C

105°C / 300 VRMS

80°C / 300 VRMS

105°C

Environmental

1) CE: EU Directive 2011/65/EU(RoHS2):

This product complies with European Directive 2011/65/EU (RoHS Directive) of the European

Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS

Compliance on this item. Consult Alpha Wire's web site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

4) Sunlight Resistance

Electrical Properties

1) Voltage Rating

2) Capacitance

3) Ground Capacitance

4) Inductance

5) Conductor DCR

6) OA Shield DCR

-30 to 105°C

10X Cable Diameter

7.5 Lbs, Maximum

Yes

(For Engineering purposes only)

300 VRMS

25 pf/ft @1 kHz, Nominal Conductor to Conductor

45 pf/ft @1 kHz, Nominal

0.22 µH/ft, Nominal

66 Ω/1000ft @20°C, Nominal

7.6 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 3280 FT

b) 1640 FT

c) 328 FT

d) 164 FT

Flange x Traverse x Barrel (inches)

18 x 12 x 8 Continuous length

12 x 10 x 5 Continuous length

6.5 x 6 x 1.9 Continuous length

6.5 x 4 x 2.5 Continuous length

[Spool dimensions may vary slightly]
