RF Coaxial Connectors, Adapters and Kits
BNC Shorting Cap or Dust
Cap for BNC Female
Model#
5085
3839
Type
Shorting cap
Dust cap
BNC Straight RF Plugs
Rating:
Maximum voltage for
hands free use:
500 Vrms.
BNC:
Body:
tarnish resistant nickel-plated brass;
Center Contact:
male: gold- plated brass; female:
gold- plated beryllium copper;
Dielectric:
PTFE.
*Performance:
4 GHz with VSWR of 1.3
maximum from 0 to 4GHz.
Model#
4488
4997
5307
5285
5344
7035*
7040*
7207*
5286
Type
BNC (m)
BNC (m)
BNC (m)
BNC (m)
BNC (f)
BNC (m)
BNC (m)
BNC (m)
BNC (m)
BNC (m)
BNC (m)
BNC (m)
BNC (m)
BNC (m)
BNC (m)
Fig.
1
1
1
2
3
2
2
1
2
4
4
4
1
2
2
Cable Group RG /U BNC
142, 142A, 142B, 223, 58, 58A, 58C,
5B, 5BA, 5BC, 8C, 141, 141A
RG58 only
174, 174A, 179B, 187, 187A, 188,
188A, 316
RG58, 58A, 58C, 141, 141A
58, 58A, 58C, 141, 141A
RG55A, 142, 142A, 223, 400
RG179. 179B, 187, 187A, 174, 188,
188A, 316
RG-223
59, 59A, 59B, 62, 62A, 62B, 62C, 210
59B, 20 AWG, Belden 1505A
6B, 18 AWG, Belden 1694A
59B, 23 AWG
59, 59A, 59B, 62, 210, Belden 8241,
8263
59A, 59B, 62, 210, Belden 8241,
8263
Belden 1407B, 1417B, 1164B, 1167B,
1418B, 11467B, 11865A
50Ω Impedance
3
50Ω Impedance Crimp
Shorting cap provides protection and supplies a
short across an input.
Dust cap protects sensitive instrument inputs and
is non-shorting.
Tarnish resistant plating.
3in (76.20mm) long chain.
1.06in
(26.92mm)
1.19in
(30.23mm)
75Ω Impedance
6702A
6703A
6704A
1.11in
(28.19mm)
0.90in
(24.88mm)
6746A
6752A
7042
Fig. 2: Crimp Style
Fig. 4: Crimp Style
Fig. 1: Compression Style
Fig. 3: Crimp Style
BNC within Series Adapters
1.26in
(32.0mm)
1.11in
(28.1mm)
1.27in
(32.3mm)
1.53in
(38.8mm)
Model#
3283
3533
3285
3284
4896
3534
3847
3846
6700
6701
6705
0.88in
(22.35mm)
6737
6738
6739
6740
3285/6739
6744
6754
Type
BNC (f/f)
BNC (m/m)
BNC (f/m/f)
BNC (f/f/f)
BNC (m/f/f)
BNC (f/m)
BNC (f/f)
BNC (f/f)
BNC (f/m/f)
BNC (f/m/f)
BNC (f/f)
BNC (f/f)
BNC (f/f/f)
BNC (f/m/f)
BNC (m/m)
BNC (f/f)
BNC (f/m/f)
Special Features
50Ω Impedance
0.92in
(23.37mm)
1.13in
(28.70mm)
Right Angle
Hermetically Sealed (b)
Isolated Ground (a)
In-line
Right Angle
Isolated Ground (a)
6701
3534
6700/6754
1.30in
(33.02mm)
1.30in
(33.02mm)
0.72in
(18.29mm)
1.50in
(38.10mm)
75Ω Impedance
0.70in
(17.78mm)
4896
3284/6738
Hermetically Sealed (b)
In-line
1.25in
(31.75mm)
1.55in
(39.37mm)
0.69in
(17.53mm)
1.40in
(35.56mm)
0.660in
(16.76mm)
Notes:
(a) Mounting hardware is isolated from outer
conductor of BNC, (b) Leakage rate less than 10
-7
cc/
sec of tracer gas at one atmosphere.
Rating:
Maximum voltage for
hands free use:
500 Vrms*, -85˚F to +329˚F (-65˚C to +165˚C).
BNC:
Shell:
tarnish resistant nickel-plated brass;Center
Contact:
male: gold-plated brass; female: gold-plated
beryllium copper;
Dielectric:
PTFE.
Bandwidth:
to 4 GHz.
3533/6740
1.32in
(33.53mm)
0.490in
(12.47mm)
3283/6737
3847/6744
See Cutout
1.30in
(32.90mm)
0.624in
(16.00mm)
6705
3846
See Cut-Out
0.50in (12.70mm)
0.47in
(11.95mm)
Panel Cut-Out for
Panel Cut-Out
3846 / 3847 / 6744
for 3846/3847
Ratings:
The components in this section have a hands free rating for use in controlled voltage environments.
However, for CE compliance these products are not intended for hand held use at voltages above 33 Vrms/70 Vdc.
www.pomonaelectronics.com
