BA33CC0FP-E2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> BA33CC0FP-E2

BA33CC0FP-E2: DescriptionFixed Positive LDO Regulator, 3.3V, BIPolar, PSSO2, ROHS COMPLIANT, TO-252, 3 PIN; CategoryPower/power management The power supply circuit; File Size354KB，10 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/

Download Datasheet Parametric Compare View All

BA33CC0FP-E2 Overview

Fixed Positive LDO Regulator, 3.3V, BIPolar, PSSO2, ROHS COMPLIANT, TO-252, 3 PIN

BA33CC0FP-E2 Parametric

Parameter Name	Attribute value
Maker	ROHM Semiconductor
Parts packaging code	TO-252
package instruction	TO-252,
Contacts	4
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum input voltage	25 V
Minimum input voltage	4 V
JESD-30 code	R-PSSO-G2
length	6.5 mm
Number of functions	1
Number of terminals	2
Working temperatureTJ-Max	125 °C
Working temperature TJ-Min
Maximum output voltage 1	3.366 V
Minimum output voltage 1	3.234 V
Nominal output voltage 1	3.3 V
Package body material	PLASTIC/EPOXY
encapsulated code	TO-252
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	2.5 mm
surface mount	YES
technology	BIPOLAR
Terminal form	GULL WING
Terminal pitch	2.3 mm
Terminal location	SINGLE
width	5.5 mm

Preview

Download Datasheet

View All

Standard Fixed Output LDO Regulator Series

Standard Fixed Output LDO Regulators

BA□□DD0 Series, BA□□CC0 Series

Standard Fixed Output LDO Regulators

with Shutdown Switch

BA□□DD0W and,BA□□CC0W Series

No.10021EBT01

●General

Description

Standard Fixed Output LDO Regulators are low-saturation regulators, available for output s up to 2A/1A. ROHM has a wide output

voltage range and package lineup with and without shutdown switches. This IC has a built-in over-current protection circuit that

prevents the destruction of the IC due to output short circuits, a thermal shut-down circuit that protects the IC from damage due to

overloading and an over-voltage protection circuit that protects the IC from surges generated in the power supply line of the IC.

●Features

1) Maximum output current : 2A (BA□□DD0),1A(BA□□CC0)

±1%

highly accurate output voltage (BA□□DD0)

3) Low saturation with PNP output

4) Built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits

5) Built-in thermal shutdown circuit for protecting the IC from damage due to overloading

6) Built-in over- voltage protection circuit that prevents the destruction of the IC due to power supply surges

7) TO220FP and HRP5 packaging (BA□□DD0) ,TO220FP and TO252 packaging(BA□□CC0)

●Applications

Used in DSP power supplies for DVD and CD players, FPDs, televisions, personal computers or any other consumer device

●Line

1A BA□□CC0 Series

Part Number

BA□□CC0WT

BA□□CC0WT-V5

BA□□CC0WFP

BA□□CC0T

BA□□CC0FP

2A BA□□DD0 Series

Part Number

BA□□DD0WT

BA□□DD0WHFP

BA□□DD0T

Symbol

3.0

○

－

○

1.5

○

3.3

○

1.8

○

5.0

○

2.5

○

6.0

－

○

3.0

○

7.0

○

－

○

3.3

○

8.0

○

5.0

○

9.0

○

9.0

○

－

○

－

○

Package

TO220FP-5

TO220FP-5(V5)

TO252-5

TO220FP-3

TO252-3

Package

TO220FP-5

HRP5

TO220FP-3

Part Number

：BA□□CC0□ □

Part Number

：BA□□DD0□ □

Details

Output Voltage Designation

□□

Output Voltage(V)

□□

Output Voltage(V)

3.0V(Typ.)

8.0V(Typ.)

033

3.3V(Typ.)

9.0V(Typ.)

5.0V(Typ.)

10.0V(Typ.)

6.0V(Typ.)

12.0V(Typ.)

7.0V(Typ.)

15.0V(Typ.)

Switch:”With W”

:Shutdown switch included

”Without W” :Shutdown switch not included

Package T : TO220FP-5(V5),TO220FP-3

FP : TO252-5,TO252-3

Symbol

Details

Output Voltage Designation

□□

Output Voltage(V)

□□

Output Voltage(V)

1.5V(Typ.)

5.0V(Typ.)

1.8V(Typ.)

9.0V(Typ.)

2.5V(Typ.)

12.0V(Typ.)

3.0V(Typ.)

16.0V(Typ.)

3.3V(Typ.)

Switch:”With W”

:Shutdown switch included

”Without W” :Shutdown switch not included

Package T : TO220FP-5,TO220FP-3

HFP: HRP5

www.rohm.com

1/9

2010.02 - Rev.B

BA33CC0FP-E2 Related Products

	BA33CC0FP-E2	BA33CC0WT	BA33CC0WT-V5	BA08CC0WT(-V5)	BA09CC0WT(-V5)	BA33CC0FP	BA33CC0T	BA33CC0WFP	BA33CC0WFP-E2
Description	Fixed Positive LDO Regulator, 3.3V, BIPolar, PSSO2, ROHS COMPLIANT, TO-252, 3 PIN	Fixed Positive LDO Regulator, 3.3V, BIPolar, ROHS COMPLIANT, TO-220FP, 5 PIN	Fixed Positive LDO Regulator, 3.3V, BIPolar, ROHS COMPLIANT, TO-220FP, 5 PIN	8V FIXED POSITIVE LDO REGULATOR, 0.5V DROPOUT, SFM5, ROHS COMPLIANT, TO-220FP, 5 PIN	9V FIXED POSITIVE LDO REGULATOR, 0.5V DROPOUT, SFM5, ROHS COMPLIANT, TO-220FP, 5 PIN	Fixed Positive LDO Regulator, 3.3V, BIPolar, PSSO2, ROHS COMPLIANT, TO-252, 3 PIN	Fixed Positive LDO Regulator, 3.3V, BIPolar, ROHS COMPLIANT, TO-220FP, 3 PIN	Fixed Positive LDO Regulator, 3.3V, BIPolar, PSSO4, ROHS COMPLIANT, TO-252, 5 PIN	Fixed Positive LDO Regulator, 3.3V, BIPolar, PSSO4, ROHS COMPLIANT, TO-252, 5 PIN
Parts packaging code	TO-252	TO-220FP	TO-220FP	TO-220FP	TO-220FP	TO-252	TO-220FP	TO-252	TO-252
Contacts	4	3	3	3	3	4	3	4	4
Reach Compliance Code	compliant	compliant	compliant	unknown	unknown	compliant	compliant	compliant	compliant
Maximum input voltage	25 V	25 V	25 V	25 V	25 V	25 V	25 V	25 V	25 V
Minimum input voltage	4 V	4 V	4 V	4 V	4 V	4 V	4 V	4 V	4 V
JESD-30 code	R-PSSO-G2	R-XSFM-T5	R-XSFM-T5	R-XSFM-T5	R-XSFM-T5	R-PSSO-G2	R-XSFM-T3	R-PSSO-G4	R-PSSO-G4
Number of functions	1	1	1	1	1	1	1	1	1
Number of terminals	2	5	5	5	5	2	3	4	4
Working temperatureTJ-Max	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Maximum output voltage 1	3.366 V	3.366 V	3.366 V	8.16 V	9.18 V	3.366 V	3.366 V	3.366 V	3.366 V
Minimum output voltage 1	3.234 V	3.234 V	3.234 V	7.84 V	8.82 V	3.234 V	3.234 V	3.234 V	3.234 V
Nominal output voltage 1	3.3 V	3.3 V	3.3 V	8 V	9 V	3.3 V	3.3 V	3.3 V	3.3 V
Package body material	PLASTIC/EPOXY	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	PLASTIC/EPOXY	UNSPECIFIED	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	SMALL OUTLINE	FLANGE MOUNT	SMALL OUTLINE	SMALL OUTLINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
surface mount	YES	NO	NO	NO	NO	YES	NO	YES	YES
technology	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR
Terminal form	GULL WING	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING	GULL WING
Terminal location	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Maker	ROHM Semiconductor	-	-	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor
ECCN code	EAR99	EAR99	EAR99	-	-	EAR99	EAR99	EAR99	EAR99
