AM1D-2412DH52Z datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> AM1D-2412DH52Z

AM1D-2412DH52Z: DescriptionDC/DC Converter; Product Weight (grams): 2.3; Input voltage min (V): 21.6; Input voltage max (V): 26.4; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Dual; Output Power (W): 1; Max Output current (A): ±0.042; Efficiency (%): 80; Max Capacitive load (µF): ±100; Package type: SIP7; Mounting: PCB; W (in): 0.24; L (in): 0.76; H (in): 0.39; W (mm): 6; L (mm): 19.5; H (mm): 10; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 5200; EMC compliance 2: EN 55032 Class B; Case material: Plastic (flammability to UL 94V-0) ; Application 4 (building automation/IoT): 1; MTBF (h): 1121000; Derating : 85; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±1.2% per 1% Vin Change; Load Regulation %: ±10; Ripple & Noise (mV p-p): 75; Switching Frequency typ (KHz): Variable 80; Short circuit protection: Momentary; CategoryPower/power management The power supply circuit; File Size954KB，15 Pages; ManufacturerAimtec; Websitehttp://www.aimtec.ca/; Environmental Compliance

Download Datasheet Parametric View All

AM1D-2412DH52Z Overview

DC/DC Converter; Product Weight (grams): 2.3; Input voltage min (V): 21.6; Input voltage max (V): 26.4; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Dual; Output Power (W): 1; Max Output current (A): ±0.042; Efficiency (%): 80; Max Capacitive load (µF): ±100; Package type: SIP7; Mounting: PCB; W (in): 0.24; L (in): 0.76; H (in): 0.39; W (mm): 6; L (mm): 19.5; H (mm): 10; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 5200; EMC compliance 2: EN 55032 Class B; Case material: Plastic (flammability to UL 94V-0) ; Application 4 (building automation/IoT): 1; MTBF (h): 1121000; Derating : 85; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±1.2% per 1% Vin Change; Load Regulation %: ±10; Ripple & Noise (mV p-p): 75; Switching Frequency typ (KHz): Variable 80; Short circuit protection: Momentary

AM1D-2412DH52Z Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Aimtec
package instruction	,
Reach Compliance Code	compliant
Factory Lead Time	15 weeks
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	26.4 V
Minimum input voltage	21.6 V
Nominal input voltage	24 V
JESD-30 code	R-PSMA-T6
length	19.5 mm
Maximum load regulation	10%
Number of functions	1
Output times	2
Number of terminals	6
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output voltage	12.36 V
Minimum output voltage	11.64 V
Nominal output voltage	12 V
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum seat height	10 mm
surface mount	NO
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	1 W
Fine-tuning/adjustable output	NO
width	6 mm

Preview

Download Datasheet

View All

Click on Series name for product info on aimtec.com

Series AM1D-Z

1 Watt | DC-DC Converter

FEATURES:

•

RoHS compliant

High efficiency up to 86%

Low profile plastic package

7 pin SIP package

•

Operating temperature -40

C to + 85

Short circuit protection

Pin compatible with multiple manufacturers

Input / Output Isolation

1000, 3000, 4000, 5200 & 6000 VDC

Models

Single output

Model

AM1D-0303SZ

AM1D-0305SZ

AM1D-0307SZ

AM1D-0309SZ

AM1D-0312SZ

AM1D-0315SZ

AM1D-0318SZ

AM1D-0324SZ

AM1D-0503SZ

AM1D-0505SZ

AM1D-0507SZ

AM1D-0509SZ

AM1D-0512SZ

AM1D-0515SZ

AM1D-0518SZ

AM1D-0524SZ

AM1D-1203SZ

AM1D-1205SZ

AM1D-1207SZ

AM1D-1209SZ

AM1D-1212SZ

AM1D-1215SZ

AM1D-1218SZ

AM1D-1224SZ

AM1D-1503SZ

AM1D-1505SZ

AM1D-1507SZ

AM1D-1509SZ

AM1D-1512SZ

AM1D-1515SZ

AM1D-1518SZ

AM1D-1524SZ

AM1D-2403SZ

AM1D-2405SZ

AM1D-2407SZ

AM1D-2409SZ

AM1D-2412SZ

AM1D-2415SZ

AM1D-2418SZ

AM1D-2424SZ

AM1D-4803SZ

AM1D-4805SZ

AM1D-4807SZ

AM1D-4809SZ

AM1D-4812SZ

AM1D-4815SZ

AM1D-4818SZ

www.aimtec.com

F 051e R11.N

REV: 08/20/A

Input

Voltage

(V)

2.97-3.63

4.5-5.5

10.8-13.2

13.5-16.5

21.6-26.4

43.2-52.5

Output

Voltage

(V)

3.3

7.2

3.3

7.2

3.3

7.2

3.3

7.2

3.3

7.2

3.3

7.2

Output

Current

Max (mA)

303

200

139

111

303

200

139

111

303

200

139

111

303

200

139

111

303

200

139

111

303

200

139

111

Isolation

(VDC)

1000

Input Current

Full Load | No

Load (mA)

399

389

379

389

415

256

247

244

253

233

241

244

111

105

111

104

105

102

103

110

Max

Capacitive

Load(uF)

220

Efficiency

Tel: +1 514 620 2722

1 of 15

Toll free: + 1 888 9 AIMTEC (924 6832)

North America only

Recommended Resources

Design of infrared communication circuit based on single chip microcomputer

Photoelectric control toy car circuit

6V dry battery charger circuit

Overspeed alarm circuit using voltage comparator

555 simple water level monitoring circuit

Radio direction finding and PJ-80 direction finding machine circuit
