Code Conductor, Blank Tongue, Long Barrel with Window Lug
For Use with Stranded Copper Conductors
Type LCC-00W
• Long barrel maximizes number of crimps and provides
premium wire pull-out strength and electrical performance
• Inspection window to visually assure full conductor insertion
• Color-coded barrels marked with Panduit and specified competitor
die index numbers for proper crimp die selection
• Enclosed barrel prevents corrosive material from entering
barrel when used in harsh environments
• Tin-plated to inhibit corrosion
• UL Recognized and CSA Certified to 35 KV** and temperature
rated to 90°C when crimped with Panduit and specified competitor
crimping tools and dies
B1.
Cable Ties
B2.
Cable
Accessories
B3.
Stainless
Steel Ties
C1.
Wiring
Duct
W
C2.
Surface
Raceway
L
B
C3.
Abrasion
Protection
INSPECTION
WINDOW
T
C4.
Cable
Management
Part Number
LCC8-00W-L
LCC6-00W-L
LCC4-00W-L
LCC2-00W-Q
Copper
Conductor
Size
#8 AWG
#6 AWG
#4 AWG
#2 AWG
#1 AWG
1/0 AWG
2/0 AWG
3/0 AWG
4/0 AWG
250 kcmil
300 kcmil
350 kcmil
400 kcmil
500 kcmil
600 kcmil
Figure Dimensions
(In.)
W
0.60
0.62
0.62
0.75
0.75
0.80
0.85
0.96
1.06
1.17
1.19
1.28
1.28
1.54
1.70
B
0.70
1.07
1.05
1.16
1.36
1.44
1.50
1.50
1.56
1.61
2.24
2.24
2.30
2.50
2.69
T
0.05
0.06
0.08
0.08
0.09
0.12
0.13
0.13
0.14
0.14
0.16
0.17
0.17
0.22
0.26
L
2.70
3.08
3.09
4.41
4.63
4.74
4.83
4.87
4.95
5.04
5.73
5.77
5.85
6.13
6.37
Panduit
Color
Code
Red
Blue
Gray
Brown
Green
Pink
Black
Orange
Purple
Yellow
White
Red
Blue
Brown
Green
Panduit
Die Index
No.‡
P21
P24
P29
P33
P37
P42
P45
P50
P54
P62
P66
P71
P76
P87
P94
Burndy
Die Index
No.‡
49
7
8
10
11
12
13
14
15
16
17
18
19
20
22
T&B
Die Index
No.‡
21
24
29
33
37
42
45
50
54
62
66
71
76
87
94
Wire Strip
Length
(In.)
3/4
1 1/8
1 1/8
1 1/4
1 7/16
1 1/2
1 9/16
1 9/16
1 5/8
1 11/16
2 5/16
2 5/16
2 3/8
2 9/16
2 3/4
Std.
Pkg.
Qty.
50
50
50
25
20
10
10
10
10
10
10
10
6
6
6
D1.
Terminals
D2.
Power
Connectors
LCC1-00W-E
LCC1/0-00W-X
LCC2/0-00W-X
LCC3/0-00W-X
D3.
Grounding
Connectors
LCC4/0-00W-X
LCC250-00W-X
LCC300-00W-X
E1.
Labeling
Systems
LCC350-00W-X
LCC400-00W-6
LCC500-00W-6
LCC600-00W-6
E2.
Labels
‡See pages D3.62 – D3.65 for tool and die information.
