Home
TELEDYNE RELAYS
Industrial Solid State Products
PART NUMBERS
Package &
Chip Type
Max Blocking Input Type
Voltage (piv)/
Line Rating
1200480
600240
D-DC
Input
Zero Cross
Switching
R-DC
Input,
Random
Turn-On
Output
Current
Amps
25
40
55
Options
NEW!
EFRQ Series
QUAD SCR OUTPUTS TO 55 AMPS PER OUTPUT, 1200 VOLTS
EFRQ-SCR
See Table
Below and
Page 58
FEATURES/BENEFITS
•
•
Four independently controlled solid state
relays in a single package.
Screw type power terminals in a high
temperature plastic housing for mechanical
ruggedness.
Constant Current Input minimizes source
current requirement (standard on D input
only)
Exposed ceramic baseplate for reduced
thermal resistance and best thermal
performance.
Constructed using Teledyne’s unique
Powertherm
TM
process. This process yields
superior thermal impedance and power
cycling capabilities through reduced thermal
interconnections, allowing for cooler, more
reliable operation.
The logic drive circuitry section uses the
latest in reliable surface mount technology.
Certifications:
- UL and ULC Recognized File #E128555
- CE # EN60947-1
Options
(Add Suffix to Part Number) - See Page 58 for full description
-012
-026
EZ Mount
TM
Non-Floating Output Terminals
•
•
Part Number Example:
EFRQ120480D55
MECHANICAL SPECIFICATION
.739
(18.77)
.160
(4.06)
.250 TYP.
(6.35)
Control In 3-32V
M5 SCREW /
NUT
.160 DIA.
(4.06)
(+COM) (1)— (2)— (3)— (4)—
•
•
•
.825
(20.96)
A1
B1
TELEDYNE RELAYS
POWERTHERM
TM
L1
.825
(20.96)
L2
2.50
1.20 (63.5)
(30.5)
EFRQ Series
A2
B2
.650
(16.51)
2.500
(63.5)
3.60
(91.44)
4.00
(101.6)
.420
(10.67)
.758
(19.3)
TYPICAL APPLICATIONS
•
•
On/Off controls of medium power AC
equipment.
Interfacing of microprocessor controls to AC
loads - lights, motors, heaters, valves,
solenoids etc.
Electromechanical line relay replacement.
Mercury displacement relay replacement.
Industrial and Process Controls.
Programmable Controller interface.
Robotics motor position and speed controls.
Light dimmers; Transformer tap switch.
.200
(5.08)
BLOCK DIAGRAM
(1)
OPTO
ISOLATED
CONTROL
DETECTION/
CONTROL
CIRCUIT
A1
AC OUTPUT A
L1
OPTO
ISOLATED
CONTROL
DETECTION/
CONTROL
CIRCUIT
•
•
•
•
•
•
GENERAL DESCRIPTION
The EFRQ series 4-pole AC Solid State Relays are
designed to save space while providing independent
control of large amounts of power in four separate
circuits. Optical isolation ensures complete protection
of each relay’s circuit control elements from load
transients in each load circuit. Teledyne’s advanced
design featuring the Powertherm
TM
process offers
users superior thermal management resulting in
excellent performance, quality and reliability.
(2)
AC OUTPUT B
A2
B2
(3)
OPTO
ISOLATED
CONTROL
DETECTION/
CONTROL
CIRCUIT
AC OUTPUT C
L2
(4)
OPTO
ISOLATED
CONTROL
DETECTION/
CONTROL
CIRCUIT
AC OUTPUT D
B1
(+ COM)
page 32
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
Updated 9/24/99
Home
TELEDYNE RELAYS
Industrial Solid State Products
NEW!
EFRQ Series
QUAD SCR OUTPUTS TO 55 AMPS PER OUTPUT, 1200 VOLTS
ELECTRICAL SPECIFICATIONS
INPUT (CONTROL) SPECIFICATIONS
Parameter
Control Voltage Range
Input Type
D
R
Input Current
Must Turn-Off Voltage
Reverse Voltage Protection
Turn-Off Current
D,R(@5Vdc)
D,R
D,R
D,R
0.25
1
-32
Min
3
4
Max
32
26
15
mA
Vdc
Vdc
mA(DC)
Surge Current Rating
See Fig 1 (Non-
Repetitive 16.7 mS)
25
40
55
250
400
600
A
Units
Vdc
OUTPUT (LOAD) SPECIFICATIONS (Contd)
Parameter
Output Current Rating
Per Output
(Load Current @85
°C)
Output Current Min
25
40
55
0.05
0.05
0.05
Max
25
40
55
A
Units
OUTPUT (LOAD) SPECIFICATION
Parameter
Voltage Code
600240
1200480
Min
24
48
47
Max
280
530
400
600
1200
1.4
Units
Thermal Resistance
Load Voltage Rating
Vac
Hz
VPeak
V
Max On-State Surge Current (Amps RMS)
25
40
55
.40
0.35
0.35
°C/W
Junction to Case (J
C
)
Per Contact
Frequency Range (Note 2)
Over Voltage Range
On-State Voltage Drop
@ Max Rate Current
Turn-On Time
D
R
Turn-Off Time
Leakage Current (Off-State)
@25
°C
dV/dt (Typical)
Isolation (All Terminals
To Heatsink) = VRMS
For 1 Min With Unit
Mounted Properly
Operating Temperature
Power Factor Range
600240
1200480
SCR Output
FIGURE 1 Max Non-Repetitive Surge Current
8.3
0.02
8.3
0.5
ms
ms
ms
mA
250
500
V/µs
4000
-40
0.5
125
1.0
V
°C
1
10
100
Number of Equal Amplitude Current Pulses at 60Hz
NOTES:
1.)
Where overvoltage transient spikes are present,
suppression may be required. An MOV suppressor and/or
a snubber circuit across the AC terminals of the module
will provide additional transient immunity.
2.)
3.)
For 400 Hz inductive load, contact factory.
Curve for 25 amp output shown. Contact factory for other
outputs.
Updated 9/24/99
Industrial Solid State Products •
800-436-8766 • www.teledynerelays.com
page 33
