F1A1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> F1A1

F1A1: DescriptionRectifier Diode, 1 Element, 1A, 50V V(RRM); CategoryDiscrete semiconductor diode; File Size150KB，2 Pages; ManufacturerFCI / Amphenol

Download Datasheet Parametric Compare View All

F1A1 Overview

Rectifier Diode, 1 Element, 1A, 50V V(RRM)

F1A1 Parametric

Parameter Name	Attribute value
Maker	FCI / Amphenol
Reach Compliance Code	unknown
Configuration	SINGLE
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.1 V
Maximum non-repetitive peak forward current	30 A
Number of components	1
Maximum operating temperature	175 °C
Maximum output current	1 A
Maximum repetitive peak reverse voltage	50 V
surface mount	NO

Preview

Download Datasheet

View All

Data Sheet

1.0 Amp MINIATURE

PLASTIC SILICON RECTIFIERS

Mechanical Dimensions

JEDEC

.091

.102

.106

.126

.800 Min.

F1A1 . . . F1A7 Series

Description

.023 Dia.

Features

LOW COST

LOW LEAKAGE

DIFFUSED JUNCTION

MEETS UL SPECIFICATION 94V-0

Electrical Characteristics @ 25

Maximum Ratings

Peak Repetitive Reverse Voltage...V

RRM

RMS Reverse Voltage...V

R(rms)

DC Blocking Voltage...V

Average Forward Rectified Current...I

F(av)

= 75°C

(Note 3)

Non-Repetitive Peak Forward Surge Current...I

FSM

@ Rated Current & Temp

Forward Voltage @ 1.0A...V

Working Peak Reverse Current...I

@ Full Cycle .375" Lead Length, T

= 75°C

DC Reverse Current @ 25°C...I

@ Rated DC Blocking Voltage @ 100°C

Typical Junction Capacitance...C

(Note 1)

Typical Thermal Resistance...R

θJC

(Note 2)

Operating & Storage Temperature Range...T

, T

STRG

F1A1 . . . F1A7 Series

F1A1

F1A2

100

F1A3

200

140

200

F1A4

400

280

400

F1A5

600

420

600

F1A6

800

560

800

F1A7

1000

700

1000

Units

Volts

Amps

Volts

µAmps

°C

/ W

°C

............................................. 1.0 ...............................................

............................................. 30 ...............................................

............................................. 1.1 ...............................................

............................................. 30 ...............................................

............................................. 5.0 ...............................................

............................................. 50 ...............................................

............................................. 15 ...............................................

............................................. 25 ...............................................

......................................... -50 to 175 ..........................................

Page 9-6

F1A1 Related Products

	F1A1	F1A7	F1A4	F1A5
Description	Rectifier Diode, 1 Element, 1A, 50V V(RRM)	Rectifier Diode, 1 Element, 1A, 1000V V(RRM)	Rectifier Diode, 1 Element, 1A, 400V V(RRM)	Rectifier Diode, 1 Element, 1A, 600V V(RRM)
Reach Compliance Code	unknown	unknown	unknown	unknown
Configuration	SINGLE	SINGLE	SINGLE	SINGLE
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	1.1 V	1.1 V	1.1 V	1.1 V
Maximum non-repetitive peak forward current	30 A	30 A	30 A	30 A
Number of components	1	1	1	1
Maximum operating temperature	175 °C	175 °C	175 °C	175 °C
Maximum output current	1 A	1 A	1 A	1 A
Maximum repetitive peak reverse voltage	50 V	1000 V	400 V	600 V
surface mount	NO	NO	NO	NO
Maker	FCI / Amphenol	-	FCI / Amphenol	FCI / Amphenol
