IS32LT3125/3125A
ABSOLUTE MAXIMUM RATINGS
VCC, OUT, EN, UV
ISET, FAULTB, CSTOR
Ambient operating temperature, T
A
=T
J
Maximum continuous junction temperature, T
J(MAX)
Storage temperature range, T
STG
Maximum power dissipation, P
DMAX
ESD (HBM)
ESD (CDM)
-0.3V ~ +45V
-0.3V ~ +7.0V
-40°C ~ +125°C
+150°C
-55°C ~ +150°C
1.96W
±2kV
±750V
Note:
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings
only and functional operation of the device at these or any other condition beyond those indicated in the operational sections of the
specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
THERMAL CHARACTERISTICS
Characteristic
Package Thermal Resistance
(Junction to Ambient), R
θJA
Package Thermal Resistance
(Junction to Pad), R
θJP
Test Conditions
On 4-layer PCB based on JEDEC standard at
1W, T
A
=25°C
Value
50.98°C/W
2.24°C/W
ELECTRICAL CHARACTERISTICS
T
J
= -40°C ~ +125°C, V
CC
=12V, the detail refer to each condition description. Typical values are at T
J
= 25°C.
Symbol
Parameter
Conditions
Min. Typ. Max.
Unit
Power Up Parameter
V
CC
V
UVLO
V
UVLO_HY
I
CC
I
SD
Supply voltage range
VCC under voltage lockout
threshold voltage
VCC under voltage lockout
voltage hysteresis
VCC supply current
Quiescent supply current
R
ISET
=20kΩ, V
EN
=high, No Fault
condition.
In shutdown mode (OUT turned off),
V
EN
= low
20
5
4.3
4.5
0.2
2
1
30
1
1
48
I
OUT
= -150mA, V
CC
= 12V, V
EN
= High
40
5.5
2
40
2
2
ms
μs
mA
42
4.7
V
V
V
mA
mA
I
SD_FLT
R
ISET
=20kΩ, V
EN
=high. IS32LT3125
OUT connected to
Supply current during LED string GND (in fault master
