SMF8V5A

Description
1000 W, UNIDIRECTIONAL, SILICON, TVS DIODE, DO-219AB
Categorysemiconductor    Discrete semiconductor
File Size396KB,3 Pages
ManufacturerLGE
Websitehttp://www.luguang.cn/web_en/index.html
Download Datasheet View All

SMF8V5A Overview

1000 W, UNIDIRECTIONAL, SILICON, TVS DIODE, DO-219AB

SMF5.0A-SMF220A
Surface Mount ESD Protection Diodes
SOD-123FL
Features
For surface mounted applications
Low profile package
Low incremental surge resistance,excellent
clamping capability
200W peak pulse power capability with a
10/1000µs wave from,repetition rate (duty
cycle):0.01%
High temperature soldering guaranteed:
260℃/10 seconds, at terminals
0.047(1.19)
0.043(1.09)
0.075(1.90)
0.067(1.70)
0.043(1.09)
0.035(0.89)
0.114(2.9)
0.098(2.5)
0.008(0.20)
0.004(0.10)
0.030(0.76)
0.018(0.45)
Mechanical Data
Case: JEDEC SOD-123FL, molded plastic
Polarity: Color band denotes positive end
( cathode ) except for bidirectional
Marking code: see TABLE 1
Mounting position: Any
Dimensions in inches and(millimeters)
0.154(3.9)
0.138(3.5)
ABSOLUTE MAXIMUM RATINGS AND CHARACTERISTICS
Ratings at 25℃ ambient temperature unless otherwise specified
SYMBOL
VALUE
UNITS
Non-repetitive peak pulse power dissipation
with a 10/1000µs waveform (NOTE 1)
Peak pulse current 10/1000
µs
wavefrom (NOTE 1)
Forw ard voltage @ I
F
=12A
Thermal resistance junction to ambient
Operating temperature junction range
Storage temperature range
NOTE:(1)Non-repetitive current pulse and derated above T
A
=25℃
P
PPM
I
PPM
V
F
R
θJA
T
J
T
STG
200
See
Table1
3.5
180
- 55 to +150
- 55 to +150
W
A
V
K/W
http://www.luguang.cn
mail:lge@luguang.cn
