233-103-H7Z115-18PN-01 datasheet, PDF

Datasheet> All Categories > The connector> The connector> 233-103-H7Z115-18PN-01

233-103-H7Z115-18PN-01: DescriptionCircular Connector Adapter, 18 Contact(s), Stainless Steel, Male-Male; CategoryThe connector The connector; File Size435KB，1 Pages; ManufacturerGlenair; Websitehttp://www.glenair.com/

Download Datasheet Parametric View All

233-103-H7Z115-18PN-01 Overview

Circular Connector Adapter, 18 Contact(s), Stainless Steel, Male-Male

233-103-H7Z115-18PN-01 Parametric

Parameter Name	Attribute value
Maker	Glenair
Reach Compliance Code	compliant
Other features	STANDARD: MIL-DTL-38999, POLARIZED
Connector type	CIRCULAR CONNECTOR ADAPTER
Contact point gender	MALE-MALE
Coupling type	THREADED
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
MIL compliance	YES
Manufacturer's serial number	233-103-H7
Mixed contacts	NO
Installation type	PANEL
Options	HERMETIC
Shell material	STAINLESS STEEL
Total number of contacts	18

Preview

Download Datasheet

View All

Bulkhead

Feed-Thrus

Connector Series

233

D38999 Series III Type

Shell Style

- Jam Nut Mount

Shell Size

Connector Type

103

Hermetic Bulkhead

Feed-Thru

Connector Material and Finish

- CRES, Passivated

- CRES, Nickel Finish

D Dia

Recommended Panel Cut-Out

233-103-H7

Jam Nut Mount Hermetic Bulkhead Feed-Thru

MIL-DTL-38999 Series III Type

Insert Arrangement

Per MIL-DTL-38999 Series III

MIL-STD-1560

Alternate Key

Position

A, B, C, D, E

(N = Normal)

1.34

2.03 Max

.23

Max

233

103

H7 Z1 11

P N

Panel Accomodation

- .0625″ (Min) .125″ (Max)

- .0625″ (Min) .250″ (Max)

- .0625″ (Min) .500″ (Max)

Contact Termination

- Pin on Jam Nut Side

- Socket on Jam Nut Side

A Thread

Panel

Accom.

F Thread

TABLE I: CONNECTOR DIMENSIONS

SHELL

SIZE

A THREAD

0.1 P-0.3L-TS-2

.6250

.7500

.8750

1.0000

1.1875

1.2500

1.3750

1.5000

1.6250

DIM

.875(22.2)

1.000(25.4)

1.250(31.8)

1.375(34.9)

1.500(38.1)

1.625(41.3)

1.750(44.5)

1.875(47.6)

2.000(50.8)

C DIM

MAX

1.090(27.7)

1.280(32.5)

1.400(35.6)

1.530(38.9)

1.660(42.2)

1.840(46.7)

1.970(50.5)

2.090(53.1)

2.210(56.1)

DIA

.698(17.7)

.822(20.9)

1.010(27.6)

1.135(28.8)

1.260(32.0)

1.385(35.2)

1.510(38.4)

1.635(41.5)

1.760(44.7)

DIM

.322(8.2)

.385(9.8)

.479(12.2)

.541(13.7)

.604(15.3)

.635(16.1)

.698(17.7)

.760(19.3)

.822(20.9)

F THREAD

CLASS 2A

.6875-24 UNEF

.8125-20 UNEF

1.000-20 UNEF

1.125-18 UNEF

1.250-18 UNEF

1.375-18 UNEF

1.500-18 UNEF

1.625-18 UNEF

1.750-18 UNS

Insert Arrangement per

MIL-DTL-38999 Series III

MIL-STD-1560

APPLICATION NOTES

Power to a given contact on one end will result in power to contact directly

opposite, regardless of identification letter.

Hermeticity = less than 1 x 10

-4

cc/sec at one atmosphere. Not for use in liquid

atmosphere.

Material/finish:

Shell, nut – CRES/passivated, carbon steel/fused tin or CRES/nickel per QQ-N-290.

Contacts – Gold Plated. Pin: alloy 52; Skt.: copper alloy

Insulator – fused vitreous glass/N.A.

Seals – ﬂuorosilicone rubber/N.A.

Metric dimensions (mm) are indicated in parentheses.

www.glenair.com

CAGE CODE 06324

Printed in U.S.A.

E-Mail: sales@glenair.com

GLENAIR, INC.

•

1211 AIR WAY

•

GLENDALE, CA 91201-2497

•

818-247-6000

•

FAX 818-500-9912

E-10
