MMDL101
Schottky Barrier Diode
SOD-323
Features
Low noise figure—6.0dB Typ.@1.0GHz.
Very Low Capacitance—less than 1.0pF @0V.
Ultra-small surface mount package.
PN junction guard ring for transient and ESD protection.
Applications
For high-efficiency UHF and VHF detector applications.
Dimensions in inches and (millimeters)
Ordering Information
Type No.
MMDL101
Marking
4M
Package Code
SOD-323
MAXIMUM RATING
@ Ta=25℃ unless otherwise specified
Parameter
DC reverse voltage
Power Dissipation
Thermal resistance,junction to ambient air
Junction temperature
Storage temperature range
Symbol
V
R
P
d
R
θjA
T
j
T
stg
Limits
7.0
200
635
150
-65-150
Unit
V
mW
℃/W
℃
℃
ELECTRICAL CHARACTERISTICS
@ Ta=25℃ unless otherwise specified
Parameter
Reverse Breakdown Voltage
Forward voltage
Reverse leakage current
Niose Figure
Total capacitance
Symbol
V
(BR)R
V
F
I
R
NF
C
T
Conditions
I
R
=10μA
I
F
=10mA
V
R
=3.0V
f=1.0GHz
V
R
=0V,f=1.0MHz
Min.
7.0
Typ.
10
0.5
20
6.0
0.88
1.0
0.6
250
Max.
Unit
V
V
nA
dB
pF
