PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0348269201
Active
Mini50 Connection Systems
Mini50 Unsealed Right-Angle Header, Dual Row, 20 Circuit, Polarization Option B,
Gray, Tube
Documents:
3D Model
Drawing (PDF)
Product Specification PS-34791-020-001 (PDF)
Application Specification AS-34791-020 (PDF)
Application Specification AS-34791-020-001 (PDF)
General
Product Family
Series
Application
Overview
Product Literature Order No
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Capable
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
Packaging Type
Pitch - Mating Interface
Polarized to Mating Part
Polarized to PCB
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Application Specification AS-34791-020-CH-001
(PDF)
Application Specification AS-34791-020-FR-001
(PDF)
Packaging Specification PK-31301-688-001 (PDF)
RoHS Certificate of Compliance (PDF)
Product Literature (PDF)
Series image - Reference only
EU ELV
Compliant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/61/2018 (27 June
2018)
Halogen-Free
Status
Not Relevant
For more information, please visit Contact US
China ROHS
ELV
RoHS Phthalates
Not Relevant
Compliant
Not Contained
PCB Headers
34826
Power, Signal, Wire-to-Board
Mini50 Connection Systems
987650-5442
Mini50
887191402741
No
20
20
Gray
10
No
No
No
Yes
Yes
Brass
Tin over Nickel
Tin over Nickel
High Temperature Thermoplastic
3.415/g
2
Right Angle
2.80mm
Yes
Tube
2.00mm
Yes
Yes
-40° to +105°C
Through Hole
4.0A
500V DC
040
Search Parts in this Series
34826 Series
Mates With
34824 Mini50 Unsealed Dual Row
Receptacle
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
SMC&WAVE
003
260
AS-34791-020, AS-34791-020-001, AS-34791-020-
CH-001, AS-34791-020-FR-001
PK-31301-688-001
PS-34791-020-001
SD-34826-001-001
