PT07P - 45107P
PT07SP - 45107RP
Jam nut receptacle
with straight backshell
for potting.
Shell size
min.
8
10
12
14
16
18
20
22
24
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
G
max.
3.2
3.2
3.2
3.2
3.2
3.2
6.4
6.4
6.4
H
8.3
11.3
14.2
17.3
20.5
23.1
26.3
29.4
32.6
K
3.2
3.2
3.2
3.2
3.2
3.2
4
4
4
L
max.
39.9
39.9
39.9
39.9
39.9
39.9
47.1
47.1
47.9
M
17.7
17.7
17.7
17.7
17.7
17.7
22.5
22.5
23.3
N
12.01
14.99
19.05
22.23
25.40
28.58
31.75
34.93
38.1
P
± 0.4
19.1
22.2
27
30.2
33.3
36.5
39.7
42.9
46
S
25.8
27
31.8
34.9
38.1
41.3
46
49.2
52.4
KK
15.4
18.6
21.7
25
28.2
31.3
34.5
37.3
40.9
PT07SE (SQ)
Jam nut receptacle with SQ braid clamping backshell.
Shell
size
8
10
12
14
16
18
20
22
24
Torque value for jam nut.
ø QG
min.
6.6
9.2
12.2
15.2
18.3
20.0
23.0
26.0
28.8
ø QH
+0.5
16
18
22
25
28
32
34
38
41
QL
max.
48.4
48.4
51.4
51.4
51.4
51.4
56.4
56.4
58.0
J
0
-0.25
13.46
16.64
20.78
23.93
27.08
30.25
33.43
36.60
39.78
K
±0.5
3.0
3.0
3.0
3.0
3.0
3.0
3.8
3.8
3.8
M
±0.13
17.68
17.68
17.68
17.68
17.68
17.68
22.45
22.45
23.39
P
(Panel thickness)
min.
max.
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
Connector size
8
10
12
14
16
18
20
22
24
Max. torque (m.N)
2,5
4
5
7
9
10
11
12
13
Right angle plug
with environmental
cable clamp
backshell.
Shell size
8
10
12
14
16
18
20
22
24
B
min.
16.6
19
20.6
23
26.2
25.8
27.4
28.9
32.1
4.3
4.3
6.7
7.8
8.4
11.2
12.9
13
16.7
C
max.
6.6
9.8
9.6
13.8
16.2
17.4
19.6
21.8
23.4
D
16.5
19.5
19.5
24
26
29.5
32
34
35.5
E
8.6
10
11.4
13.2
14.8
15.8
17.3
18.8
20.2
L
53
55
58
61
65
69
71
72
78
Q
18.6
21.4
25.8
29
32.2
34.9
38.5
41.7
44.7
13
PT/451
PT08E (SR) - 45108EC
PT08SE (SR) - 45108RC
SPT08A (SR)
SPT08E (SR)
