5KP240CA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 5KP240CA

5KP240CA: DescriptionTrans Voltage Suppressor Diode, 5000W, 240V V(RWM), Bidirectional, 1 Element, Silicon, PLASTIC, 5KP, 2 PIN; CategoryDiscrete semiconductor diode; File Size66KB，3 Pages; ManufacturerDiodes Incorporated

Download Datasheet Parametric View All

5KP240CA Overview

Trans Voltage Suppressor Diode, 5000W, 240V V(RWM), Bidirectional, 1 Element, Silicon, PLASTIC, 5KP, 2 PIN

5KP240CA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Diodes Incorporated
package instruction	O-PALF-W2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum breakdown voltage	296 V
Minimum breakdown voltage	266 V
Shell connection	ISOLATED
Maximum clamping voltage	388 V
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	O-PALF-W2
JESD-609 code	e0
Maximum non-repetitive peak reverse power dissipation	5000 W
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	BIDIRECTIONAL
Maximum power dissipation	8 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	240 V
surface mount	NO
technology	AVALANCHE
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

5KP5.0(C)A(S) - 5KP240(C)A(S)

5000W TRANSIENT VOLTAGE SUPPRESSOR

Features

5000W Peak Pulse Power Dissipation

5.0V - 170V Standoff Voltages

Glass Passivated Die Construction

Uni- and Bi-directional Version Available

Excellent Clamping Capability

Fast Response Time

Plastic Case Material has UL Flammability

Classification Rating 94V-0

5KP

Dim

Min

25.40

0.95

Max

8.60

1.07

9.53

5KW

Min

25.40

—

1.20

Max

9.00

1.30

8.00

Mechanical Data

Case: 5KP/5KW, Transfer Molded Epoxy

Terminals: Solderable per MIL-STD-202,

Method 208

Polarity Indicator: Cathode Band

(Note: Bi-directional devices have no polarity

indicator.)

Marking: Type Number

Weight: 2.1 grams (approx.)

All Dimensions in mm

“S” Suffix Designates 5KW Package

No “S” Designates 5KP Package

Maximum Ratings

@ T

= 25°C unless otherwise specified

Symbol

Value

5000

Unit

Characteristic

Peak Pulse Power Dissipation

(Non repetitive current pulse derated above T

= 25°C)

( Note 1)

Peak Forward Surge Current, 8.3ms Single Half Sine

Wave Superimposed on Rated Load (JEDEC Method)

(Notes 1, 2, & 3)

Steady State Power Dissipation at T

= 75°C,

Lead Lengths @ 9.5mm(Note 1)

Instantaneous Forward Voltage @ I

= 100A

(Notes 1, 2, & 3)

Operating and Storage Temperature Range

FSM

, T

STG

400

8.0

3.5

-55 to +150

°C

Notes:

1. Valid provided that the terminals are maintained at a distance of 10mm from case at 25°C.

2. Measured with 8.3ms single half sine-wave. Duty cycle = 4 pulses per minute maximum.

3. Unidirectional units only.

DS21504 Rev. H-2

1 of 3

5KP5.0(C)A(S) - 5KP240(C)A(S)
