5-1617090-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> relay> 5-1617090-4

5-1617090-4: DescriptionPOWER/SIGNAL RELAY, DPDT, LATCHED, 0.047A (COIL), 12VDC (COIL), 567mW (COIL), 2A (CONTACT), PANEL MOUNT; CategoryMechanical and electronic products relay; File Size109KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

5-1617090-4 Overview

POWER/SIGNAL RELAY, DPDT, LATCHED, 0.047A (COIL), 12VDC (COIL), 567mW (COIL), 2A (CONTACT), PANEL MOUNT

5-1617090-4 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum coil current (DC)	0.047 A
Coil power	567 mW
Coil resistance	254 Ω
Maximum coil voltage (DC)	12 V
Coil/Input Power Type	DC
Maximum contact current (AC)	2 A
Maximum contact current (DC)	2 A
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1617090
Installation features	PANEL MOUNT
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
Relay action	LATCHED
Relay function	DPDT
Relay type	POWER/SIGNAL RELAY
seal	HERMETICALLY SEALED
surface mount	NO
Termination type	SOLDER HOOK

5-1617090-4 Preview

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

LS-9517M Product Details

Military/Aerospace High Performance Relays

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

LS-9517M

(5-1617090-4)

T E I nternal N umber: 5 - 1 6 1 7 0 9 0 - 4

Product Highlights:

LS Half-size Relay Series

Input Voltage = 12 VDC

C ontact Arrangement = 2 Form C , DPDT, 2 C /O

C ontact C urrent Rating = 2 Amps.

Polarized, Bistable C oil Magnetic System

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

RELAY

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type = Solder Hook Terminals

Electrical Characteristics:

Input Voltage (VDC ) = 12

C ontact C urrent Rating (Amps.) = 2

C oil Polarity Protection Diode = Without

Transistor Driver = Without

C oil Resistance (?) = 254

MOSFET Driver = Without

C oil Power Measurement = Milliwatts

C oil Power, Nominal (mW) = 567

Actuating System = DC

Shock = 100G's, 6ms

Vibration = 30G's, 10 to 2500Hz

Body Related Features:

Series

= LS Half-size Relay

Contact Related Features:

Mounting Options = Panel Mount

Enclosure = Hermetically Sealed

Configuration Related Features:

C ontact Arrangement

= 2 Form C , DPDT, 2 C /O

C oil Magnetic System = Polarized, Bistable

C oil Suppression Diode = Without

C oil Latching = Double

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not suitable for lead free processing

Conditions for Usage:

Temperature Range (?C ) = -65 – +125

Other:

Brand = C II

Additional Information:

Product Line Information

5-1617090-4 Related Products

	5-1617090-4	LS-9517M
Description	POWER/SIGNAL RELAY, DPDT, LATCHED, 0.047A (COIL), 12VDC (COIL), 567mW (COIL), 2A (CONTACT), PANEL MOUNT	POWER/SIGNAL RELAY, DPDT, LATCHED, 0.047A (COIL), 12VDC (COIL), 567mW (COIL), 2A (CONTACT), PANEL MOUNT
Is it Rohs certified?	incompatible	incompatible
Maker	TE Connectivity	TE Connectivity
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Maximum coil current (DC)	0.047 A	0.047 A
Coil power	567 mW	567 mW
Coil resistance	254 Ω	254 Ω
Maximum coil voltage (DC)	12 V	12 V
Coil/Input Power Type	DC	DC
Maximum contact current (AC)	2 A	2 A
Maximum contact current (DC)	2 A	2 A
Contact/Output Power Type	AC/DC	AC/DC
Manufacturer's serial number	1617090	LS
Installation features	PANEL MOUNT	PANEL MOUNT
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-65 °C	-65 °C
Relay action	LATCHED	LATCHED
Relay function	DPDT	DPDT
Relay type	POWER/SIGNAL RELAY	POWER/SIGNAL RELAY
seal	HERMETICALLY SEALED	HERMETICALLY SEALED
surface mount	NO	NO
Termination type	SOLDER HOOK	SOLDER HOOK
