5-1617748-2

Description
POWER/SIGNAL RELAY, SPDT, MOMENTARY, 28VDC (COIL), 25A (CONTACT), PANEL MOUNT
CategoryMechanical and electronic products    relay
File Size113KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

5-1617748-2 Online Shopping

Suppliers Part Number Price MOQ In stock
5-1617748-2 - - View Buy Now

5-1617748-2 Overview

POWER/SIGNAL RELAY, SPDT, MOMENTARY, 28VDC (COIL), 25A (CONTACT), PANEL MOUNT

5-1617748-2 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codecompliant
ECCN codeEAR99
Factory Lead Time21 weeks
Maximum coil voltage (DC)28 V
Maximum contact current (AC)25 A
Maximum contact current (DC)25 A
Contact/Output Power TypeAC/DC
Manufacturer's serial number1617748
Installation featuresPANEL MOUNT
Relay actionMOMENTARY
Relay functionSPDT
Relay typePOWER/SIGNAL RELAY
surface mountNO
Termination typeSOLDER HOOK
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
FCA-125-6 Product Details
Military/Aerospace Mid-Range Relays
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
FCA-125-6
(5-1617748-2)
T E I nternal N umber: 5 - 1 6 1 7 7 4 8 - 2
Product Highlights:
l
FC A 10-25 Amp Relay Series
l
DC Actuating System
l
C oil Voltage = 28 VDC
l
C ontact Arrangement = 1 Form C , SPDT, 1 C /O
l
C urrent Rating = 25 Amps.
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
RELAY
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Terminal C onfiguration
= Solder Hook
Electrical Characteristics:
l
Actuating System
= DC
l
C oil Voltage (VDC )
= 28
l
C urrent Rating (Amps.)
= 25
Termination Related Features:
l
Terminal Plating
= Tin-Lead
l
Auxiliary C ontacts = Without
Body Related Features:
l
Series = FC A 10-25 Amp Relay
l
Mount Type
= Bottom Mount
Configuration Related Features:
l
C ontact Arrangement
= 1 Form C , SPDT, 1 C /O
l
C oil Suppression Diode
= Without
l
C oil Magnetic System = Polarized, Monostable
Industry Standards:
l
Government/Industry Qualification = Yes
l
Government/Industry Part Number = M6106/19-006
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Other:
l
Brand = C II
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
