589363: Description46MHz - 1000MHz RF/MICROWAVE DIRECTIONAL COUPLER, PLUG-IN, 8 PIN; CategoryWireless rf/communication Radio frequency and microwave; File Size254KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

589363 Overview

46MHz - 1000MHz RF/MICROWAVE DIRECTIONAL COUPLER, PLUG-IN, 8 PIN

589363 Parametric

Parameter Name	Attribute value
Maker	TE Connectivity
Reach Compliance Code	unknown
Characteristic impedance	75 Ω
Maximum input power (CW)	23.98 dBm
Maximum operating frequency	1000 MHz
Minimum operating frequency	46 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
RF/Microwave Device Types	DIRECTIONAL COUPLER

Preview

Download Datasheet

View All

589363

E-Series 75 Ohm Directional Coupler

46-1000 MHz

Features

•

Coupling 8db Typical.

8 Pin Plug-in.

Description

M/A-COM’s 589363is a high performance 75 Ohm Coupler on a

8 Pin Plug-in package.

Electrical Specifications @25°C

Frequency Range 46 - 1000 MHz

Input Return Loss

46– 600 MHz

600 - 1000 MHz

Units

dB

Nominal

—

Typical

—

Minimum

—

Maximum

16

18.5

Output Return Loss

46– 600 MHz

600 - 1000 MHz

46 MHz

870 MHz

1000 MHz

46 MHz

870 MHz

1000 MHz

46-1000 MHz

46 MHz

870 MHz

1000 MHz

46 MHz

870 MHz

1000 MHz

46-1000 MHz

dB

—

19

17

8.5

8.7

8.8

8.5

8.7

8.8

0.15

1.8

2.3

2.4

1.8

2.3

2.4

0.15

Couplong

Coupshrt

Coupling Flatness

Thrulong

Thrulshrt

Thrulong Flatness

Specifications subject to change without notice.

V 2.0

North America:

Tel. (800) 366-2266, Fax (800) 618-8883

Asia/Pacific:

Tel.+81-44-844-8296, Fax +81-44-844-8298

Europe:

Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020

Visit www.macom.com for additional data sheets and product information.

1
