Radiation Hardened, SEE Hardened, Non-Inverting,
Quad CMOS Driver
ISL7457SRH
The ISL7457SRH is a radiation hardened, SEE hardened,
high speed, non-inverting, quad CMOS driver. It is
capable of running at clock rates up to 40MHz and
features 2A typical peak drive capability and a nominal
on-resistance of just 3.5Ω. The ISL7457SRH is ideal for
driving highly capacitive loads, such as storage and
vertical clocks in CCD applications. It is also well suited to
level-shifting and clock-driving applications.
Each output of the ISL7457SRH can be switched to either
the high (V
H
) or low (V
L
) supply pins, depending on the
related input pin. The inputs are compatible with both
3.3V and 5V CMOS logic. The output enable (OE) pin can
be used to put the outputs into a high-impedance state.
This is especially useful in CCD applications, where the
driver should be disabled during power down.
The ISL7457SRH also features very fast rise and fall
times which are typically matched to within 1ns. The
propagation delay is also matched between rising and
falling edges to typically within 1.5ns.
The ISL7457SRH is available in a 16 lead ceramic
flatpack package and specified for operation over the full
-55°C to +125°C ambient temperature range.
Specifications for Rad Hard QML devices are
controlled by the Defense Supply Center in
Columbus (DSCC). The SMD numbers listed here
must be used when ordering.
Detailed Electrical Specifications for these
devices are contained in SMD 5962-08230. A
“hot-link” is provided on our website for
downloading.
ISL7457SRH
Features
• Electrically Screened to SMD 5962-08230
• QML Qualified per MIL-PRF-38535 Requirements
• Full Mil-temp Range Operation . T
A
= -55
°
C to +125
°
C
• Radiation Hardness
- TID [50-300 rad(Si)/s] . . . . . . . .10krad(Si) min
• SEE Hardness
- LET (SEL and SEB Immunity)40MeV/mg/cm
2
min
- LET [SET =
ΔV
OUT
< 15V,
Δt
< 500ns] . . . . . . .
40MeV/mg/cm
2
• 4 Channels
• Clocking Speeds up to 40MHz
• 11ns/12ns Typical t
R
/t
F
with 1nF Load (15V bias)
• 1ns Typical Rise and Fall Time Match (15V bias)
• 1.5ns Typical Prop Delay Match (15V bias)
• Low Quiescent Current - < 1mA Typical
• Fast Output Enable Function - 12ns Typical (15V bias)
• Wide Output Voltage Range
- 0V
≤
V
L
≤
8V
- 2.5V
≤
V
H
≤
16.5V
• 2A Typical Peak Drive Current (15V Bias)
• 3.5Ω Typical ON-Resistance (15V bias)
• Input Level Shifters
• 3.3V/5V CMOS Compatible Inputs
Applications
• CCD Drivers, Clock/line Drivers, Level-Shifters
Pin Configuration
ISL7457SRH
(16 LD FLATPACK)
TOP VIEW
INA
OE
INB
V
L
GND
NC
INC
IND
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
V
S
+
OUTA
OUTB
NC
V
H
OUTC
OUTD
V
S
-
May 16, 2011
FN6874.1
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774 | Copyright Intersil Americas Inc. 2009, 2011. All Rights Reserved
Intersil (and design) is a trademark owned by Intersil Corporation or one of its subsidiaries.
All other trademarks mentioned are the property of their respective owners.
