• short circuit, over load, over voltage, brown-out,
battery low, and battery polarity protections
• withstand 2G vibration test
• efficiency up to 86%
MODEL
PSF-155-A
PSF-155-B
PSF-155-C
PSF-155-D
Notes:
output
voltage
(Vdc)
output
current
1
max
(A)
output
power
2
max
(W)
ripple
and noise
3
max
(mVp-p)
efficiency
typ
(%)
Vo1
Vo2
Vo1
Vo2
Vo3
Vo1
Vo2
Vo1
Vo2
Vo3
13.8
13.8
13.8
13.8
5
27.6
27.6
27.6
27.6
5
11.2
3.88
10.1
3.88
3
5.6
2.1
5.1
2.1
3
155
155
155
155
100
150
100
150
100
100
150
100
150
100
86
85
86
85
1. Vo2 battery discharge current must not exceed 40% of the rated power.
2. Maximum total combined power (rated power).
3. At 20 MHz bandwidth using a 12” twisted pair-wire, each output terminated with a 47 µF and 0.1 µF parallel capacitors.
PART NUMBER KEY
PSF-155 -
X
-
XXX
Base Number
Output Voltage
A = 13.8 Vdc, 13.8 Vdc
B = 13.8 Vdc, 13.8 Vdc, 5 Vdc
C = 27.6 Vdc, 27.6 Vdc
D = 27.6 Vdc, 27.6 Vdc, 5 Vdc
Chassis
CNF = enclosed
CF = enclosed with fan
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PSF-155
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
12/12/2014
page
2 of 7
INPUT
parameter
voltage
surge voltage
frequency
current
inrush current
leakage current
power factor
at 115 Vac
at 230 Vac
at 115 Vac, cold start
at 230 Vac, cold start
at 264 Vac
at full load
0.94
for maximum of 5 seconds
47
2.5
1.5
55
108
1
conditions/description
min
90
127
typ
max
264
373
300
63
units
Vac
Vdc
Vac
Hz
A
A
A
A
mA
OUTPUT
parameter
line regulation
load regulation
voltage accuracy
hold-up time
setup time
rise time
adjustability
temperature coefficient
AC OK
battery low
conditions/description
low line to high line, at rated load
Vo1, Vo3
10% to 100% rated load
Vo1
Vo3
Vo1
Vo3
at 115/230 Vac, full load
at 115 Vac, full load, cold start
at 230 Vac, full load, cold start
at 115/230 Vac, full load
Vo1
Vo1, 0°C~50°C
PSF-155-A, PSF-155-C
PSF-155-B, PSF-155-D
PSF-155-A, PSF-155-B
PSF-155-C, PSF-155-D
TTL open collector output
relay contact output
<12 V ±3%
<22 V ±3%
3200
2400
20
±10
±0.03
min
typ
±0.5
±0.5
±1.5
±2
±3
30
max
units
%
%
%
%
%
ms
ms
ms
ms
%
%/°C
PROTECTIONS
parameter
over voltage protection
over current protection
battery cut off
conditions/description
Vo1, latch off mode
auto recovery, hiccup mode
Vo1, Vo3
Vo2
PSF-155-A, PSF-155-B
PSF-155-C, PSF-155-D
min
115
110
100
9.6
19
10
20
10.4
21
typ
max
150
units
%
%
%
Vdc
Vdc
SAFETY & COMPLIANCE
parameter
isolation voltage
isolation resistance
safety approvals
EMI/EMC
1
RoHS
Note:
conditions/description
input to output
input to ground
output to ground
input to output at 500 Vdc
UL 60950-1, EN 60950-1
min
3,000
1,500
500
100
typ
max
units
Vac
Vac
Vac
MΩ
EN 55022, EN 61000-6-(1,3), EN 61000-3-(2,3),
EN 55024, EN 50204, EN 61204-3, EN 61000-4-(2, 3, 4, 5, 6, 8, 11)
2011/65/EU
1. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives.
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PSF-155
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
12/12/2014
page
3 of 7
ENVIRONMENTAL
parameter
operating temperature
storage temperature
operating humidity
storage humidity
vibration
non-condensing
non-condensing
at 10~500 Hz, 10 min per cycle for 60 minutes
each test along the X, Y, and Z axis
conditions/description
see derating curve
min
-20
-40
20
10
2
typ
max
70
85
90
90
units
°C
°C
%
%
G
DERATING CURVES
Load vs. Temperature
Load vs. Input Voltage
(at 25°C)
100
80
60
40
20
0
100
80
70
60
50
40
30
20
0
-20
Load (%)
all other models
Safe operating area
Load (%)
“CF”, enclosed with fan
or with 23 CFM fan
~
~
-10
0
10
20
30
40
50
60
70
90
95
100
105
110
115
120
264
Ambient Temperature (°C)
Input Voltage (Vac) 60 Hz
MECHANICAL
parameter
dimensions
weight
conditions/description
enclosed: 179 x 98 x 38
enclosed with fan:179 x 98 x 55.4
enclosed
enclosed with fan
0.64
0.68
min
typ
max
units
mm
mm
kg
kg
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PSF-155
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
12/12/2014
page
4 of 7
MECHANICAL DRAWING
CNF
units: mm
CN1 Pin Connections
PIN
1
2
3
4
5
6
7
1
8
2
Function
AC/L
AC/N
FG
⏚
-Vo1
+Vo1
+Vo2 (+ BAT)
-Vo2 (- BAT)
+Vo3 (+5 V)
1 2
3 4
1
2
3
PIN
CN2 Pin Connections
Function
PSF-155-A, PSF-155-C
3
AC OK
BAT LOW
PSF-155-A: (13.8 V/20 mA)
PSF-155-C: (27.6 V/20 mA)
PSF-155-B, PSF-155-D
4
AC OK
BAT LOW
CF
units: mm
CN1 Pin Connections
PIN
1
2
3
4
5
6
7
1
8
2
Function
AC/L
AC/N
FG
⏚
-Vo1
+Vo1
+Vo2 (+ BAT)
-Vo2 (- BAT)
+Vo3 (+5 V)
1 2
3 4
1
2
3
PIN
CN2 Pin Connections
Function
PSF-155-A, PSF-155-C
3
AC OK
BAT LOW
PSF-155-A: (13.8 V/20 mA)
PSF-155-C: (27.6 V/20 mA)
PSF-155-B, PSF-155-D
4
AC OK
BAT LOW
Notes:
1.
2.
3.
4.
To protect product damage do not connect the GND port with -BAT port.
PSF-155-B and PSF-155-D only.
For PSF-155-A & PSF-155-C, CN2 mates with JST XHP-3 or equivalent and JST SXH-001 T-P0.6 or equivalent.
For PSF-155-B & PSF-155-D, CN2 mates with JST XHP-4 or equivalent and JST SXH-001 T-P0.6 or equivalent.
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PSF-155
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
12/12/2014
page
5 of 7
BATTERY CHARGING SPECIFICATIONS
Block Diagram
Alarm Circuit for
PSF-155-A & PSF-155-C
Alarm Circuit for
PSF-155-B & PSF-155-D
PSF-155-A & PSF-155-C
Alarm Signal for AC OK and Battery Low
Function
AC OK
Description
The signal is low when the power
supply turns on
The signal is high when the power
supply turns off
The signal is low when the voltage of
the battery is below:
12 V (PSF-155-A), 22 V (PSF-155-C)
The signal is high when the voltage of
the battery is above:
12 V (PSF-155-A), 22 V (PSF-155-C)
Alarm Output
Low
(0.3 V max. at 30 mA)
High/open
(external voltage < 50 V)
Low
(0.3 V max. at 30 mA)
High/open
(external voltage < 50 V)
Battery
Low
Notes:
1. Alarm signal is sent out through “AC OK” and “Battery Low” pins.
2. An external voltage source is required for this function. The maximum applied voltage is 50 V and the maximum sink current is 30 mA.
