BLF8G19LS-170BV

Power LDMOS transistor

Rev. 3 — 1 May 2015

Product data sheet

1. Product profile

1.1 General description

170 W LDMOS power transistor with improved video bandwidth for base station

applications at frequencies from 1800 MHz to 1990 MHz.

Table 1.

Typical performance

Typical RF performance at T

case

= 25



C in a common source class-AB production test circuit.

Test signal

2-carrier W-CDMA

[1]

1-carrier W-CDMA

[2]

[1]

[2]

(MHz)

1930 to 1990

1805 to 1880

(mA)

1300

(V)

L(AV)

(W)

(dB)

18.0

19.8



(%)

ACPR

(dBc)

31

40

Test signal: 3GPP test model 1; 64 DPCH; PAR = 8.4 dB at 0.01 % probability on CCDF;

carrier spacing 5 MHz.

Test signal: 3GPP test model 1; 64 DPCH; PAR = 7.2 dB at 0.01 % probability on CCDF.

1.2 Features and benefits



Excellent ruggedness

High efficiency

Low thermal resistance providing excellent thermal stability

Decoupling leads to enable improved video bandwidth (100 MHz typical)

Lower output capacitance for improved performance in Doherty applications

Designed for low memory effects providing excellent pre-distortability

Internally matched for ease of use

Integrated ESD protection

Integrated current sense

Compliant to Directive 2002/95/EC, regarding Restriction of Hazardous Substances

(RoHS)

1.3 Applications



RF power amplifier for W-CDMA base stations and multi carrier applications in the

1800 MHz to 1990 MHz frequency range
